Legion LT-50MV Steam Kettles
Description
Legion LT-50 Direct Steam Kettle • 50 Gal (189 L)
2/3 Jacketed • Integrated 2-Speed Twin-Shaft Mixer • 30 psiBuilt for volume kitchens that refuse to compromise on performance or sanitation, the Legion LT-50 stationary kettle combines seamless 304 stainless steel construction with a powerful, factory-mounted agitator. Whether you’re finishing delicate sauces or simmering hearty stews, this 50-gallon workhorse delivers uniform heating, hands-free mixing and dependable draw-off — all Made in the USA and ASME/NSF compliant.
Kettle Highlights
- Seamless deep-drawn 304 stainless steel liner with matching 304L jacket for maximum hygiene and durability.
- 2/3 steam jacket provides fast, even heat transfer up to 30 psi operating pressure.
- 2″ compression draw-off valve (304 SS) with removable perforated disc strainer (¼″ holes) for easy product transfer and particulate control.
- (3) heavy-duty 2″ Ø stainless legs, reinforced bracing and adjustable flanged feet keep the kettle rock-solid on uneven floors.
- Deep-dome optional cover available (recommended when operating without mixer).
Factory-Mounted Twin-Shaft Mixer (MV Series)
- Two-speed, totally-enclosed gear motor tailored for 20-100 gal kettles — select low speed for gentle circulation or high speed for vigorous agitation.
- 304 SS anchor-style main agitator hugs the kettle wall; removable nylon blades continuously scrape for zero scorch & no manual stirring.
- Counter-rotating secondary beater breaks up particulates and improves heat distribution.
- Actuator-assisted lift raises the agitator, scraper and bridge for effortless product loading or cleaning.
- Bayonet mounts allow both shafts to release in seconds for sanitation or for running the kettle without the mixer.
- Built-in safety interlock prevents high-speed start-ups unless the mixer is fully engaged.
Technical Specifications
| Capacity | 50 gal | 189 L |
|---|---|
| Construction | Seamless 304 SS liner & 304L jacket, 304 SS legs/valves |
| Jacket Coverage | 2/3 jacketed (steam charged) |
| Operating Pressure | 30 psi (max.) |
| Steam Connections | ¾″ NPT inlet / ½″ NPT condensate outlet |
| Draw-Off Valve | 2″ compression type with ¼″ perforated strainer |
| Agitator Drive | MV twin-shaft, 2-speed gear motor (15:1 reduction) |
| Agitator Materials | Main anchor – 304 SS & nylon scraper Secondary beater – 304 SS |
| Legs / Base | (3) 2″ Ø stainless legs with reinforced bracing & flanged, height-adjustable feet |
| Overall Height (lid closed) | Approx. 69 in | 175 cm (bridge lowered) |
| Compliance | ASME coded; NSF listed; built in the USA |
Dimensions shown are from manufacturer’s data sheet. Allow additional clearance for mixer swing-out, utility hook-ups and routine service.
Perfect For
- Soups, chowders & stews
- Custards, pie fillings & pudding bases
- Reductions, stocks & sauces
- Pasta, oatmeal or rice cooking
- Any high-volume scratch preparation that benefits from constant, hands-free agitation
Covered by Legion’s 12-month parts & labor warranty. Extended coverage available — ask your representative for details.
