Legion LSWT-80MV Steam Kettles
Description
80-Gallon Stationary Direct Steam Kettle with Twin-Shaft Mixer
Legion LSWT-80 MV | Wall-Bracket Mounted, Full Jacket, 30 psiBuilt for relentless, high-volume production, the Legion LSWT-80 MV combines a fully jacketed 80-gallon steam kettle with an industrial-duty twin-shaft agitator. 100 % stainless construction, rapid heat transfer and gentle, uniform mixing make it the go-to workhorse for kettled sauces, soups, fillings and more.
Why you’ll love it
- 304 SS food-contact liner & jacket – corrosion-resistant, easy to sanitize and built to last.
- Full 30 psi direct-steam jacket – faster heat-up and recovery for better throughput.
- Integrated MV twin-shaft mixer – two-speed gear motor drives a 304 SS anchor agitator + counter-rotating beater for complete, lump-free blending.
- Removable nylon scraper blades continuously wipe the kettle wall to eliminate burn-on and maximise heat transfer efficiency.
- 2 in. draw-off valve with ¼ in. perforated strainer disc for safe, particle-free dispensing of stocks and broths.
- One-piece domed cover with gas-assist lift keeps condensation out of the work zone and lifts effortlessly for operator comfort.
- Seam-welded 304 SS wall brackets – no floor stand to clean underneath; installs at the perfect working height for your crew.
- Made in the USA, built to ASME & NSF standards, and backed by Legion’s industry-leading warranty.
Built-in twin-shaft agitator
- Enclosed, balanced aluminium bridge with positive rim-lock for safe, vibration-free operation.
- Totally-enclosed gear motor, right-angle output, two-speed selection:
• Low: 23 RPM main / 60 RPM beater
• High: 46 RPM main / 120 RPM beater - Actuator-assisted lift raises the mixer, scraper and bridge clear for product checks or kettle cleaning.
- Bayonet-mount agitator and beater remove in seconds—no tools required.
- Safety interlock prevents high-speed starts and stops mixing when the bridge is lifted.
Technical specifications
| Capacity | 80 gal | 303 L |
|---|---|
| Kettle type | Stationary, wall-bracket mounted, deep-drawn design |
| Liner & interior | 304 stainless steel, polished food-contact finish |
| Jacket | 304 stainless, full coverage, 30 psi max. operating pressure |
| Heating source | Direct injected steam (customer-supplied) |
| Agitator drive | 2-speed gear motor, 2 HP (high), 1 HP (low) |
| Draw-off valve | 2 in. compression type with ¼ in. perforated SS strainer |
| Cover | One-piece domed, gas-assist lift, 304 SS |
| Support | Seam-welded 304 SS wall arms (hardware supplied by installer) |
| Construction | All exterior surfaces 304 stainless steel |
| Certifications | ASME Section VIII, NSF/ANSI 4, UL listed motor components |
Note: Steam supply & return piping, electrical connection and wall reinforcement must be provided by the installer. Dimensions may vary slightly when a 2 in. draw-off valve is specified.
Warranty
Legion backs every kettle with a 12-month parts & labour warranty (15 months from ship date). Extended coverage is available—ask your representative for details.
