Legion LSWT-60MV Steam Kettles
Description
Legion 60-Gallon Stationary Direct-Steam Kettle with 2-Speed Mixer
Model LSWT-60-MV • Full Jacket • Wall-Mounted • 30 psiPurpose-built for commissaries, institutional kitchens and food processors that demand rock-solid reliability, the LSWT-60-MV combines a 60-gallon deep-drawn kettle with an integrated twin-shaft agitator. Batch after batch, you’ll enjoy rapid, even heating, hands-free mixing and effortless clean-out—all in a compact wall-mounted design that keeps aisles clear and floors easy to sanitize.
Why You’ll Love It
- True 304 Stainless Construction – liner, full steam jacket and seam-welded support arms resist corrosion and pitting for years of trouble-free service.
- Full-Jacket Efficiency – 360° steam jacket rated 30 psi surrounds the kettle for lightning-fast heat-up and unsurpassed temperature uniformity.
- Integrated 2-Speed Mixer – twin-shaft agitator (23 rpm / 46 rpm) with counter-rotating beater and removable nylon scrapers keeps products homogenous and prevents scorching.
- Heavy-Duty 2 ″ Draw-Off Valve – sanitary compression type with ¼ ″ perforated strainer lets you portion or filter with confidence.
- Space-Saving Wall Bracket – stainless support arms are factory seam-welded to the jacket for a clean installation and easy wash-down.
- Actuator-Assisted Cover & Mixer Lift – fingertip-easy lifting improves operator safety and speeds change-over.
- Made in the USA – ASME- and NSF-compliant craftsmanship backed by Legion’s legendary quality.
Technical Specifications
| Capacity | 60 gal | 227 L |
|---|---|
| Kettle Type | Stationary, full-jacketed, direct steam |
| Operating Pressure | 30 psi (2.07 bar) max |
| Construction | 304 SS liner & jacket; 304 SS wall-mount support arms (seam welded) |
| Draw-Off | 2 ″ compression valve with ¼ ″ perforated disk strainer |
| Agitator System | Twin-shaft, 2-speed (Low 23 rpm / High 46 rpm main agitator) Counter-rotating beater 60 rpm / 120 rpm 304 SS anchor arm with removable nylon scrapers |
| Steam Connections | 1 ″ NPT inlet | ¾ ″ NPT condensate return |
| Overall Width (A) | 32.5 in | 826 mm |
| Overall Depth (C) | 38.2 in | 970 mm |
| Height – Rim (J1) | 73.7 in | 1 872 mm* |
| Recommended Mount Ht. (T) | 10.5 in below rim* |
| Cover | One-piece domed, 304 SS, actuator assisted |
| Certifications | ASME, NSF |
*Refer to installation manual for exact bracket placement and clearances.
Popular Add-Ons
- Single or dual swing-nozzle fill faucet with wall bracket
- 48 ″ flexible spray hose for quick rinse-down
- Measuring strip or tri-basket cook/cool inserts
- 1/8 ″ perforated strainer disk for finer filtration
- In-wall carrier kit for recessed mounting
Upgrade your production line with the Legion LSWT-60-MV and experience faster throughput, consistent results and years of dependable service—all from an American-made industry leader.
