Legion LSWT-50MV Steam Kettles
Description
Legion LSWT-50 Stationary Direct-Steam Kettle & 2-Speed Mixer
50-gallon • wall-mount • full-jacket • 30 psiEngineered for high-volume kitchens that refuse to compromise on speed or consistency, the Legion LSWT-50 combines a 50-gallon, full-jacketed direct-steam kettle with a powerful twin-shaft agitator. From silky sauces to hearty chili, every batch cooks evenly and pours cleanly— all while the wall-bracket design keeps valuable floor space wide-open.
Why This Kettle Rocks
- 304 stainless deep-drawn liner & jacket deliver exceptional corrosion resistance.
- Full jacket rated 30 psi for lightning-fast heat-up with an external steam source.
- Twin-shaft, two-speed mixer (1 ½ HP high / ¾ HP low) keeps even the thickest recipes in motion.
- Anchor-style main agitator hugs the bowl, while nylon scraper blades wipe every surface clean.
- Counter-rotating beater (304 SS) breaks up clumps and guarantees uniform results.
- Actuator-assisted bridge lift & one-piece domed cover—smooth, safe, and effortless.
- 2" compression draw-off valve with ¼" perforated disk strainer speeds portioning & cleaning.
- Wall-mount support arms (304 SS, seam-welded) free up floor space and simplify sanitation.
- Made in the USA and built to ASME & NSF standards.
Integrated Twin-Shaft Agitator
- Enclosed, balanced aluminum bridge protects gears and bearings.
- Right-angle gear motor with 15 : 1 reduction ratio.
- Selectable High (46 RPM agitator / 120 RPM beater) or Low (23 RPM agitator / 60 RPM beater) for total recipe control.
- Bayonet-mount agitator & beater remove in seconds for CIP or when a mixer isn’t required.
- Positive rim-lock, high-speed start interlock, and automatic shutoff when the bridge lifts.
Technical Specifications
| Capacity | 50 gal | 189 L |
|---|---|
| Kettle Type | Stationary, wall-bracket mounted, full jacket |
| Operating Pressure | 30 psi (2.07 bar) max |
| Construction | 304 SS liner, jacket, domed cover & support arms |
| Heating Source | Direct external steam (NPT steam inlet & return) |
| Draw-Off Valve | 2" compression, ¼" perforated strainer |
| Mixer Speeds | Low 23 RPM / High 46 RPM (main agitator) |
| Mixer Motor | ¾ HP (low) • 1 ½ HP (high) — totally enclosed |
| Overall Width (A) | 29.5 in / 750 mm |
| Bowl Depth (C) | 36.3 in / 922 mm |
| Wall Mount Span (Z) | 30.0 in / 762 mm |
Popular Add-Ons (sold separately)
- 48" flexible spray hose assembly
- Single or double pantry faucet with 12" or 18" swing nozzle
- Measuring strip or tri-basket cooking insert
- Draw-off drain hose & kettle care kit
- In-wall carrier for reinforced mounting
Legion Industries reserves the right to improve or modify products without notice. Need help configuring accessories? Contact our experts.
