Legion 20-Gallon Stationary Direct Steam Kettle with 2-Speed Mixer
Model LSWT-20 – Full Jacket • Wall-Mounted • 30 psiBuilt for compact kitchens that refuse to compromise on output, this U.S-made Legion kettle combines rapid, even steam heating with a powerful twin-shaft agitator. The result is flawless soups, sauces, custards, and reductions—batch after batch.
Why You’ll Love It
- 20 gal (76 L) deep-drawn kettle formed from 304 stainless for exceptional durability and easy cleaning.
- Full 304 stainless steam jacket distributes heat evenly and slashes cook times.
- Rated 30 psi for fast heat-up and recovery—perfect for high-turn menus.
- Factory-installed 2″ compression draw-off valve with ¼″ perforated disk strainer lets you portion or filter product without clogging.
- Seam-welded wall-mount support arms keep the floor clear and simplify daily wash-down.
- All components meet or exceed ASME & NSF standards and are proudly made in the USA.
Integrated Twin-Shaft Mixer
- 2-speed, totally-enclosed gear motor: Low 23 rpm / 60 rpm and High 46 rpm / 120 rpm (main / secondary).
- Anchor-style main agitator and counter-rotating beater—both 304 stainless—sweep every inch of product.
- Removable nylon scraper blades prevent scorching and are dishwasher-safe.
- Actuator-assisted bridge lift provides full kettle access for loading, tasting, or cleaning.
- Positive rim lock with safety interlock—mixer will not start in high speed unless the bridge is fully seated.
- Bayonet-mount shafts remove in seconds for effortless sanitation or when using the kettle as a stand-alone cooker.
Technical Specifications
| Capacity | 20 gal (76 L) |
|---|---|
| Operating Pressure | 30 psi max |
| Heating Source | Direct external steam, full jacket |
| Liner & Jacket Material | 304 stainless steel |
| Support Arms | 304 stainless, seam-welded, wall-mount |
| Draw-Off Valve | 2″ compression with ¼″ perforated disk strainer |
| Mixer Motor | Two-speed, ½ HP (low) / 1 HP (high) |
| Main Agitator RPM | 23 rpm (low) / 46 rpm (high) |
| Secondary Beater RPM | 60 rpm (low) / 120 rpm (high) |
| Steam Connections | ¾″ NPT inlet, ½″ NPT return |
| Overall Width (A) | 23″ (584 mm) |
| Overall Depth (C) | 31.4″ (798 mm) |
| Recommended Mounting Height (T) | 16.5″ (419 mm) above finished floor |
Steam supply, drain plumbing, and mounting hardware must be installed by a qualified technician in accordance with local codes.
Product Weight:
593.0 lbFrequently Asked Questions
