60-Gallon Direct-Steam Wall-Mount Kettle with 2-Speed Mixer

Legion Model LSWC-60-MV | Full Jacket | 30 psi | Made in USA

Built for the toughest production kitchens, this 60-gallon Legion wall-console kettle delivers rapid, even heating and consistent, hands-free mixing. Its deep-drawn, full-jacketed body in food-grade 304 stainless steel pairs with a heavy-duty twin-shaft agitator to handle sauces, soups, custards, and chowders day after day with absolute reliability.

Why You’ll Love It

  • True one-person operation – 2-speed agitator scrapes, blends, and lifts at the touch of a switch.
  • 304 stainless liner & full jacket resist corrosion and simplify sanitation.
  • 30 psi rating accelerates heat-up time for faster batch turns.
  • 2" sanitary draw-off valve with ¼" perforated disk strainer speeds draining of broths, stocks, and particulates.
  • Space-saving wall-console mount keeps the floor clear while rear plumbing connections hide utilities from view.
  • Actuator-assisted domed cover & mixer bridge tilt out of the way for effortless loading and cleaning.
  • Made in the USA and built to rigorous ASME & NSF standards.

Integrated Twin-Shaft Agitator

  • Enclosed, balanced aluminum mixer bridge with safety interlock – agitator stops when bridge is raised.
  • Totally-enclosed gear motor, two-speed:
    • LOW : 23 RPM main / 60 RPM secondary
    • HIGH: 46 RPM main / 120 RPM secondary
  • 304 SS anchor agitator hugs kettle contour for complete movement of product.
  • Counter-rotating 304 SS secondary beater breaks up lumps and improves heat transfer.
  • Removable nylon scraper blades wipe the entire cooking surface, eliminating scorch zones.
  • Bayonet mounts allow both agitators to be removed without tools for cleaning or kettle-only use.

Technical Specs

Capacity 60 gal / 227 L
Construction (liner & jacket) 304 Stainless Steel, deep-drawn, satin finish
Operating Pressure 30 psi (207 kPa)
Heating Surface Full Jacket, direct external steam
Agitator Drive 2-speed gear motor, twin-shaft, fixed mount tilt-out
Horsepower High 2 HP / Low ¾ HP
Draw-Off Valve 2″ compression-type, 304 SS, with ¼″ perforated disk strainer
Cover One-piece, domed, actuator-assisted stainless cover
Utilities Steam inlet & outlet: ¾″ NPT (rear); Electrical: 208/230/460 V, 3-phase (others on request)
Overall Height 74″ (bridge down)
Wall Projection 39.6″
Shipping Weight Contact for exact crate weight

Certifications

  • ASME Section VIII – “U” stamped pressure vessel
  • NSF Listed for foodservice sanitation
  • UL & ETL electrical assemblies

What’s Included

  • 60-gal jacketed kettle with wall-console mount
  • Twin-shaft, 2-speed mixer assembly
  • Actuator-assisted domed cover
  • 2″ draw-off valve & ¼″ perforated disk strainer
  • Rear utility connection kit
  • Owner’s manual & factory-testing certificate

Popular Add-Ons (sold separately)

  • Fill faucets with swing nozzles
  • 48″ rinse spray hose (vinyl or stainless)
  • Draw-off drain hose
  • Perforated basket or nylon bag inserts
  • Automatic water-fill meter
  • Full-body insulation jacket
Important: This kettle operates on direct external steam. A suitable steam generator or boiler, condensate return, and pressure-regulating devices are required and are not included.

Looking for a different capacity or configuration? Explore the full Legion LSWC series or chat with our team for custom builds up to 100 gallons.

Product Weight:

823.0 lb
Manufacturer Legion
Shipping Weight 823.0lbs
Jacket full jacket
Base wall mount
Type stationary
Kettle Liner stainless steel
Capacity 60 gal
Specifications Stationary Direct Steam Wall-Mount Kettle, with mixer, 60-gallon, 304 stainless steel liner, full jacket, 2" draw-off valve with perforated 1/4" hole strainer, stainless steel construction, stainless steel reinforced console boxes with rear plumbing connections, 30 psi
