Legion 50 Gallon Stationary Direct-Steam Kettle with Integrated Mixer
Wall-Console Mounted • Full Jacket • 30 psiEngineered for high-volume, scratch-made production, this 50-gallon Legion kettle pairs rapid, even steam heating with a rugged two-speed agitator so your crew can braise, simmer, sauté or finish thick sauces without constant scraping.
Key Advantages
- 304 stainless-steel liner & full jacket – seamless, corrosion-resistant and effortless to sanitize.
- Direct-steam heating rated at 30 psi for fast heat-up and quick recovery between batches.
- Factory wall-console mount with reinforced 304 stainless service boxes keeps steam plumbing off the floor and out of the way.
- Integrated twin-shaft agitator (two-speed) featuring an anchor-style main paddle, counter-rotating beater and removable nylon scrapers for complete bowl coverage.
- Actuator-assisted bridge lift – swing the mixer clear in seconds for loading, unloading or deep cleaning.
- One-piece domed stainless cover, also actuator assisted, traps heat and reduces energy loss.
- 2″ compression draw-off valve with ¼″ perforated stainless disk strainer for smooth, clog-free portioning.
- ASME-code stamped and NSF listed – built in the USA for years of everyday service.
What’s Included
- 50-gal full-jacket direct-steam kettle body
- MV-series twin-shaft mixer assembly (low & high speed)
- Actuator-assisted domed cover
- 2″ draw-off valve with ¼″ perforated disk strainer
- Rear steam & condensate connections (¾″ NPT)
- Operator manual & manufacturer’s warranty
Mixer Performance
| Speeds | Low & High (selector switch) |
|---|---|
| Horsepower | Low: ¾ HP | High: 1 ½ HP |
| Main Agitator RPM | Low: 23 RPM | High: 46 RPM |
| Secondary Beater RPM | Low: 60 RPM | High: 120 RPM |
| Agitator Style | Anchor paddle with counter-rotating beater & nylon scrapers |
Technical Specifications
| Model | LSWC-50-MV |
|---|---|
| Capacity | 50 gal / 189 L |
| Operating Pressure | 30 psi (direct steam) |
| Liner Material | 304 stainless steel, deep-drawn |
| Jacket Material | 304 stainless steel, full jacket |
| Draw-off Valve | 2″ compression with ¼″ perforated disk strainer |
| Steam Inlet / Condensate Outlet | ¾″ NPT (each, rear connection) |
| Approx. Rim Height | 38″ / 965 mm |
| Overall Height (mixer raised) | ≈70.5″ / 1 791 mm |
| Front-to-Back (overall) | 25.1″ / 638 mm |
Requires an external regulated steam source (not included). Professional installation must meet all applicable local codes.
