Legion LSWC-40MV Steam Kettles
Description
Legion 40-Gallon Stationary Direct-Steam Wall-Mount Kettle with 2-Speed Mixer
Model LSWC-40MV | Full Jacketed • 30 psi • 304 Stainless SteelBoost batch consistency and kitchen throughput while freeing up valuable floor space. The Legion LSWC-40MV combines a heavy-duty, fully jacketed 40-gallon kettle with a powerful twin-shaft agitator, all in a sanitary wall-console mount that keeps utilities and controls safely out of the way.
Key Features & Benefits
- 304 SS deep-drawn kettle liner and full jacket for unbeatable corrosion resistance.
- Twin-shaft, 2-speed agitator (46/23 RPM) thoroughly blends high-viscosity foods and delicate sauces alike.
- Anchor-style main agitator with removable nylon scraper blades sweeps the entire sidewall for even heat transfer and zero burn-on.
- Counter-rotating secondary beater (120/60 RPM) breaks up lumps and speeds reduction.
- Actuator-assisted bridge lift plus quick-acting rim lock for effortless tool-free cleaning.
- One-piece domed stainless cover, spring-assisted for safe, single-hand operation.
- 2" compression draw-off valve paired with a perforated ¼" disk strainer—ideal for stocks and chowders.
- Reinforced stainless console boxes with rear plumbing connections keep the cookline clutter-free.
- 30 psi operating pressure delivers rapid heat-up while meeting ASME & NSF sanitation standards.
- Made in the USA and built to order by Legion Industries.
Technical Specifications
| Capacity | 40 gal | 151 L |
|---|---|
| Mounting Style | Wall-console, stationary (in-wall carrier available) |
| Operating Pressure | 30 psi (steam supplied by house boiler) |
| Construction | 304 SS liner, jacket & consoles; sanitary TIG welds |
| Agitator Motor | High speed 1½ HP @ 46 RPM main / 120 RPM beater Low speed ¾ HP @ 23 RPM main / 60 RPM beater |
| Draw-Off Valve | 2" compression type with ¼" perforated strainer disk |
| Overall Width (A) | 29.5 in (748 mm) |
| Overall Depth (D) | 25.1 in (638 mm) |
| Console Height (J1) | 69.5 in (1 765 mm) |
| Shipping Weight | Approx. 680 lb (309 kg) |
| Agency Compliance | ASME, NSF |
Popular Options & Accessories
- Single or double fill faucets (12" / 18" swing nozzles)
- 48" flexible spray hose assembly (vinyl or stainless)
- Automatic water-fill meter
- Perforated disk strainers (⅛" or custom)
- Basket or nylon bag inserts for pasta & stocks
- Full body insulation or higher operating pressure
Need a different size or configuration? Explore the full Legion LSWC range from 20 – 100 gallons or chat with our team for a custom build.
