Legion LSP-80 Steam Kettles
Description
Legion LSP-80 LOW-RIM™ Stationary Direct Steam Kettle
80-Gallon • Full Jacket • 304 Stainless Steel • Made in USAEngineered for high-volume, high-performance kitchens, the Legion LSP-80 delivers 80 gallons (303 L) of consistent, even-heated cooking power. Its seamless deep-drawn 304 stainless liner and full jacket design provide maximum durability and heat transfer, while the pedestal-mounted LOW-RIM™ profile keeps the rim height comfortable for safe, efficient operation.
Key Features
- Seamless deep-drawn 304 stainless steel kettle liner—no crevices for food to hide.
- Full 304L stainless steel jacket rated to 30 psi for rapid, uniform heating.
- 304 stainless pedestal tube & base, seam-welded to jacket for rock-solid stability.
- 2" compression-type draw-off valve with ¼" perforated disk strainer for easy portioning & debris capture.
- Actuator-assisted, one-piece domed cover—opens effortlessly, stays open safely.
- LOW-RIM™ design keeps kettle rim lower than comparable models, reducing lift height and operator fatigue.
- NSF & ASME compliant; fabricated, tested, and assembled in the USA.
Why You’ll Love It
- Faster batch turnaround—full jacket exposes more surface area to steam, cutting heat-up times.
- Better yield & flavor—gentle steam heat minimizes scorching and product loss.
- Sanitary & easy to clean—mirror-smooth interior wipes down quickly; no rivets or seams.
- Lifetime value—heavy-gauge stainless construction stands up to daily institutional use.
Specifications
| Model | LSP-80 (pedestal mounted) |
|---|---|
| Capacity | 80 gal / 303 L |
| Inside Diameter (A) | 39.0 in (991 mm) |
| Inside Depth (B) | 22.0 in (559 mm) |
| Operating Pressure | 30 psi (206 kPa) max. |
| Steam Connections | Inlet 1" NPT • Return ¾" NPT |
| Draw-off Valve | 2" compression type, 304 SS, with ¼" perforated strainer |
| Cover | One-piece domed stainless cover, actuator assisted |
| Construction | All 304 / 304L stainless steel—liner, jacket, pedestal tube, and base |
| Approx. Rim Height | 62.3 in (1581 mm) with cover |
| Certifications | ASME, NSF (others upon request) |
What’s Included
- Fully assembled LSP-80 kettle with pedestal base
- Actuator-assisted stainless cover
- 2" draw-off valve & ¼" disk strainer
- Installation & operation manual
Requires an adequate supply of 30 psi clean steam (not included). Professional installation recommended.
