Legion | SKU:
LSP-60
Legion LSP-60 Steam Kettles
$9,943.73
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Legion LSP-60 Steam Kettles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Legion LSP-60 Steam Kettles
$9,943.73
Unit price
/
Unavailable
Description
Legion LSP-60 Stationary Direct Steam Kettle – 60 Gal.
Full-jacketed • 304 stainless steel • Pedestal mountedEngineered for relentless, high-volume production, the American-made Legion LSP-60 gives you 60 gallons (227 L) of perfectly even direct-steam cooking in a rock-solid, LOW-RIM™ pedestal design that’s easy to load, stir and clean.
Key Features
- Seamless deep-drawn 304 stainless steel kettle liner – no interior weld seams.
- Full 304L stainless steam jacket for rapid, uniform heat transfer.
- 30 psi operating pressure handles soups, sauces, pastas and more.
- 2″ compression-type draw-off valve with 304 stainless tube & welds.
- Perforated ¼″ stainless disk strainer keeps solids out of the valve.
- One-piece domed cover with spring-assist actuator for effortless lifting.
- Heavy-duty 304 stainless pedestal tube welded to jacket for unmatched stability.
- LOW-RIM™ profile lowers rim height for safer, more ergonomic access.
- Built in the USA to ASME, NSF and other applicable standards.
At-a-Glance Specs
| Model | LSP-60 |
|---|---|
| Capacity | 60 gal / 227 L |
| Heat Source | Direct external steam (customer supplied) |
| Operating Pressure | 30 psi (207 kPa max) |
| Interior Diameter | 32.5″ / 826 mm |
| Interior Depth | 22.3″ / 566 mm |
| Overall Height | 73.7″ / 1 873 mm (cover closed) |
| Steam Inlet / Return | 1″ NPT inlet, ¾″ NPT return |
| Draw-off Connection | 2″ compression valve outlet |
| Construction | All 304 stainless liner, jacket, pedestal tube & base |
| Standard Accessories | Perforated ¼″ disk strainer, actuator-assisted cover |
| Country of Origin | USA |
Ideal For
- High-volume restaurants & hotels
- Central commissaries & ghost kitchens
- Schools, hospitals & correctional facilities
- Large-batch soups, sauces, stocks, chilies & pasta
Steam supply required:
This kettle is designed for connection to an external 30 psi clean steam source (not included).
Verify boiler capacity and proper steam plumbing before ordering.
Looking for agitators, faucets or basket inserts? Contact us for the complete line of factory-approved accessories for the Legion LSP-60.
Features & Specs
Features & Specs
Manufacturer
Legion
Shipping Weight
350.0lbs
Base
pedestal base
Kettle Jacket
full jacket
Capacity
50 - 70 gallon
Kettle Liner
304 stainless steel
Specifications
Stationary Direct Steam Kettle, 60-gallon, 304 stainless steel liner, full jacket, 2" draw-off valve with perforated 1/4" hole strainer, actuator-assisted cover, stainless steel construction, pedestal base, 30 psi
