Legion 50-Gallon Stationary Direct Steam Kettle with Integrated Twin-Shaft Mixer
Model LS-50 | Made in the USABuilt for high-volume production of soups, sauces, stews and fillings, the Legion LS-50 combines fast, even steam-jacket cooking with a powerful, two-speed agitator system. The result—perfectly mixed product, zero scorching and rock-solid reliability shift after shift.
Key Features & Benefits
- 50 gal. (189 L) working capacity—ideal for mid-size commissaries and institutions
- 304 stainless steel liner & full jacket for exceptional corrosion resistance and easy sanitation
- 30 psi operating pressure delivers rapid heat transfer up to 300 °F (149 °C)
- Deep-drawn, seamless kettle body eliminates hard-to-clean crevices
- Integrated MV mixer:
- 304 SS anchor agitator hugs the kettle contour
- Counter-rotating 304 SS secondary beater for complete product turnover
- Removable nylon scraper blades keep surfaces perfectly clean
- Two-speed gear motor (Low 23/60 RPM • High 46/120 RPM)
- Actuator-assisted bridge & agitator lift for effortless kettle access
- Bayonet-mount shafts for quick tool-less removal and cleaning
- 2" sanitary draw-off valve supplied with ¼" perforated strainer—perfect for broths & stocks with particulates
- Three heavy-duty 2" Ø legs with adjustable flanged feet for floor anchoring
- ASME-stamped & NSF listed for code compliance
Specifications
| Capacity | 50 gal. / 189 L |
|---|---|
| Construction | 304 SS liner, jacket, legs & mixer components |
| Jacket Style | Full steam jacket, deep-drawn |
| Operating Pressure | 30 psi max (207 kPa) |
| Heating Source | External direct steam connection (NPT) |
| Mounting | Stationary, 3-leg with adjustable flanged feet |
| Draw-off Valve | 2" compression, ¼" perforated strainer disc |
| Mixer Type | Twin-shaft anchor agitator & counter-rotating beater |
| Agitator Speeds | Low 23 RPM / 60 RPM beater • High 46 RPM / 120 RPM beater |
| Mixer Motor | ¾ HP (low) • 1½ HP (high) totally-enclosed gear motor |
| Utilities | 208/230/460 V, 3-phase, 60 Hz (other voltages available) |
| Certifications | ASME, NSF |
Need a custom draw-off size, higher pressure rating or hinged lid? Contact us—Legion builds to order.
Product Weight:
330.0 lbFrequently Asked Questions
