Legion 25-Gallon Stationary Direct Steam Kettle with Integrated Mixer
Full-Jacketed • 304 Stainless Steel • 30 psi Operating PressureEngineered for demanding commercial kitchens, this 25-gallon Legion kettle couples rapid, even steam heating with a powerful twin-shaft agitator—giving you unbeatable temperature control and hands-free mixing for sauces, soups, custards, pastas, fillings and more.
Kettle Highlights
- 25 gal (95 L) working capacity—ideal for midsize production runs
- 304 stainless steel liner, jacket and legs for superior corrosion resistance
- Deep-drawn, full steam jacket surrounds side & bottom for uniform heating
- 30 psi maximum jacket pressure for fast heat-up and recovery
- 2 in. compression draw-off valve with removable ¼ in. perforated strainer—perfect for quickly portioning or filtering product
- Sturdy three-leg base with adjustable flanged feet—leveling is quick on any floor surface
- Made in the USA to meet or exceed applicable ASME & NSF standards
MV Twin-Shaft Agitator System
- Enclosed, balanced aluminum bridge with totally-enclosed gear motor
- Anchor-style main agitator (304 SS) hugs kettle contour; counter-rotating beater boosts circulation
- Two-speed operation (23/46 RPM main, 60/120 RPM beater) for delicate to heavy-body products
- Nylon scraper blades continuously clean the interior surface—no scorched product, less manual labor
- Bayonet-mount tooling removes in seconds for sanitation or when kettle is used without mixing
- Actuator-assisted lift raises the bridge, scraper and agitator clear for CIP or batch change-over
- Positive rim lock plus built-in safety circuit prevents high-speed starts when bridge is up
Ideal Applications
- Soups, chowders & stews
- Caramel, fondant & confectionery fillings
- Custards, puddings & pastry cream
- Pasta, rice & grain cook-ups
- Sous-vide base stocks and sauces
Technical Specifications
| Capacity | 25 gal (95 L) |
|---|---|
| Operating Pressure | 30 psi (steam jacket) |
| Liner / Jacket Material | 304 stainless steel |
| Draw-Off Valve | 2 in. compression, 304 SS | ¼ in. perforated strainer included |
| Mounting | Stationary, 3 legs with adjustable flanged feet |
| Agitator Type | Mixer Heads – Model MV twin-shaft, anchor + counter-rotating beater |
| Agitator Speeds | Low 23/60 RPM | High 46/120 RPM (main/beater) |
| Agitator Motor | Two-speed, ½ HP (low) / 1 HP (high) | TEFC gear motor |
| Country of Origin | USA |
Peace-of-Mind Coverage
- 12-month parts & labor warranty from date of installation
- Extended warranty packages available at time of purchase
Need a different capacity, voltage or optional accessories? Contact us—Legion’s modular design makes it easy to configure the perfect kettle for your kitchen.
Product Weight:
237.0 lbFrequently Asked Questions
