Legion 20-Gallon Stationary Direct Steam Kettle with Integrated MV Mixer
Full-Jacketed • 304 Stainless Steel • 30 psi Operating PressureBring high-volume cooking and consistent product quality to the heart of your kitchen. This 20-gallon Legion kettle combines rapid, even steam heating with a factory-mounted, twin-shaft agitator that mixes, scrapes and aerates—all while you focus on other tasks.
Why You’ll Love It
- Full 30 psi steam jacket delivers faster heat-up with zero hot spots.
- MV two-speed mixer (46 / 23 RPM) keeps ingredients perfectly blended, from thin broths to thick chili.
- Anchor-style agitator with removable nylon scraper blades sweeps the entire kettle wall and base.
- Counter-rotating beater (120 / 60 RPM) accelerates cooking times and prevents product “build-up.”
- 2" draw-off valve with ¼" perforated strainer lets you portion or drain while filtering out solids.
- (3) heavy-duty legs with adjustable flanged feet allow secure, level anchoring.
- Actuator-assisted bridge lift with positive rim lock; mixing stops automatically when the bridge is raised.
- All 304 stainless steel construction stands up to daily wash-downs and corrosive ingredients.
- Built in the USA to meet or exceed ASME & NSF standards.
Technical Specifications
| Capacity | 20 gal / 76 L |
|---|---|
| Construction | 304 SS liner, jacket, legs & mixer components |
| Jacket Type | Full, double-wall steam jacket |
| Operating Pressure | 30 psi (2.1 bar) max. |
| Heat Source | Direct steam (external boiler required) |
| Mixer Type | Twin-shaft, anchor agitator + counter-rotating beater |
| Agitator Speeds | High 46 RPM • Low 23 RPM |
| Beater Speeds | High 120 RPM • Low 60 RPM |
| Agitator Motor | 1 hp (high) / ½ hp (low) totally-enclosed gear motor |
| Draw-Off Valve | 2" compression type, ¼" perforated strainer |
| Legs | (3) 1 ⅝" Ø legs with adjustable flanged feet |
| Certifications | ASME, NSF |
Dimensions and electrical data available on request.
Perfect For
- Soups, sauces & gravies
- Custards, puddings & pie fillings
- Chili, chowders & stews
- Rice, pasta & grain dishes
- Vegetable sautés & braises
Warranty
Backed by Legion’s 12-month parts & labor warranty for worry-free operation.
Product Weight:
193.0 lbFrequently Asked Questions
