Legion 100-Gallon Stationary Direct Steam Kettle with Twin-Shaft Mixer
Model LS-100 MV | Full Jacket | 25 psi | Made in USAEngineered for high-volume kitchens that demand uncompromising durability, the Legion LS-100 MV combines a deep-drawn, fully jacketed steam kettle with a factory-mounted two-speed agitator. From delicate sauces to thick chowders, you’ll achieve even heating, consistent texture and hands-free mixing in a single, 100-gallon vessel.
Key Kettle Features
- 100 gal. (379 L) working capacity
- 304 stainless steel liner, jacket & leg socket supports
- Full-jacketed design for rapid, uniform heat transfer
- 25 psi operating pressure for fast cook times
- 2 in. compression draw-off valve with ¼ in. perforated strainer – ideal for stock & soup service
- One-piece domed cover with actuator assist (stays up, swings away effortlessly)
- (4) 2 in. diameter legs with adjustable flanged feet and reinforced bracing for rock-solid stability
- NSF & ASME compliant construction
Integrated MV Twin-Shaft Agitator
- Balanced aluminum mixer bridge – fixed mount, tilt-out for cleaning
- Two-speed gear motor (Low: 23 RPM / High: 46 RPM main agitator)
- Counter-rotating beater (Low: 60 RPM / High: 120 RPM) keeps product in constant motion
- 304 SS anchor-style main agitator hugs the kettle wall
- Removable nylon scraper blades wipe the entire cooking surface, preventing burn-on
- Actuator-assisted lift raises bridge, scraper & beater clear for batch change-out
- Positive rim-lock latch & safety interlock stop mixing when bridge is lifted
- Bayonet-mount shafts remove in seconds for sanitation or when you need the kettle without agitation
Perfect For
- Soups, stews & chili
- Custards, sauces & gravies
- Pasta fillings & mashed potatoes
- Reduction of stocks & bone broth
Technical Specifications
| Capacity | 100 gal. / 379 L |
|---|---|
| Construction | 304 SS liner, jacket & exterior; deep-drawn, one-piece kettle body |
| Operating Pressure | 25 psi (full jacket) |
| Agitator Drive | Two-speed, 1 HP (Low) & 2 HP (High) gear motor |
| Main Agitator RPM | Low 23 RPM • High 46 RPM |
| Secondary Beater RPM | Low 60 RPM • High 120 RPM |
| Draw-Off Valve | 2 in. compression, ¼ in. perforated strainer |
| Cover | 304 SS, one-piece domed, actuator assisted |
| Mounting | (4) leg-mounted, adjustable flanged feet |
| Steam Supply | Customer-provided direct steam @ 25 psi |
| Certifications | ASME • NSF |
Warranty
Legion provides 12 months on-site parts & labor (15 months from date of shipment) on this kettle and mixer assembly. Extended coverage is available – ask your sales representative for details.
Product Weight:
900.0 lbFrequently Asked Questions
