Legion LGB-80MV Steam Kettles
Description
Legion LGB-80 Stationary Gas Kettle with Mixer 80 gal (303 L) • 2/3-Jacketed • 131,400 BTU
Built for demanding production kitchens, the Made-in-USA Legion LGB-80 combines a rugged 304 stainless self-contained kettle with a powerful twin-shaft mixer. From creamy sauces to hearty stews, this 80-gallon workhorse delivers uniform, scorch-free cooking and hands-free agitation that boosts throughput and food quality.
Why you’ll love it
- Rapid, even heating – 2/3 jacket surrounds product for full-sidewall heat transfer.
- Deep-drawn 304 SS liner with seamless radius lip for maximum sanitation and easy cleaning.
- Power-assist mixer – twin-shaft anchor agitator with counter-rotating beater scrapes every inch of the kettle surface; two-speed gear motor handles thin soups to viscous fillings.
- Precise thermostat control (150 °F – 260 °F) maintains consistent cook temperatures.
- Full-body insulation locks in heat, slashes energy costs and keeps the exterior cool to the touch.
- Electronic ignition (120 V) for reliable, match-free starts.
- 2″ compression draw-off valve with 304 SS tube—smooth product flow and fast clean-out.
- Comprehensive safety suite: pressure relief, low-water cut-off, air eliminator, sight glass, gauge & safety pilot.
- Factory-adjusted 131,400 BTU natural-gas burner (propane option available).
- Adjustable bullet feet level the four-leg base on uneven floors.
Technical specifications
| Capacity | 80 gal / 303 L |
|---|---|
| Heat source | Natural gas, 131,400 BTU hr (propane 131,100 BTU hr) |
| Gas connection | 3/4" IPS, supply pressure 5–7" W.C. (NG) / 12–14" W.C. (LP) |
| Electrical | 120 V, 1 φ, 50/60 Hz, 1 A (ignition & controls) |
| Construction | 304 SS liner & draw-off tube, 304L SS jacket, welded 304 SS outer casing & control console |
| Mixer drive | Two-speed gear motor • Low: 1 HP – 23 RPM agitator / 60 RPM beater • High: 2 HP – 46 RPM agitator / 120 RPM beater |
| Agitator style | Anchor-type with removable nylon scraper blades + counter-rotating beater |
| Temperature range | 150 °F – 260 °F (65 °C – 127 °C) thermostat |
| Standard accessories | Perforated ¼″ disc strainer, one-piece domed cover (actuator-assisted) |
| Overall dimensions* | A Ø (kettle shell): 32.5″ | B rim ht.: 27.6″ | C overall ht.: 45.1″ | J to cover top: 87.6″ |
*Dimensions shown in inches. Consult drawing for full footprint and service clearances.
Utility requirements
- 3/4″ rigid gas line with upstream manual shut-off valve.
- 120 V / 15 A grounded receptacle within 6 ft (1.8 m) of control console.
- Ventilation per local codes for 131,400 BTU gas appliance.
- Potable water source recommended for jacket fill/inspection.
