Legion LGB-60MV Steam Kettles
Description
Legion LGB-60 “Insulated for Safety”™ Stationary Kettle 60-gal • Gas-Fired • Twin-Shaft Mixer
Engineered for high-volume production kitchens, the Legion LGB-60 delivers 60 gallons (227 L) of perfectly even heat and continuous agitation in a fully self-contained, jacketed steam kettle. A deep-drawn 304 stainless interior, 2/3 steam jacket and factory-installed MV twin-shaft agitator make quick work of soups, sauces, fillings and more—while the insulated outer jacket keeps heat where it belongs and operators protected.
Why You’ll Love It
- 60-gal capacity handles up to 480 lb of product per batch.
- Gas-fired, 106,800 BTU burner reaches set temp fast; Natural or LP gas configurable.
- 2/3 steam jacket provides gentle, uniform heating from 150 °F – 260 °F (65 °C – 127 °C).
- MV twin-shaft agitator (2-speed) keeps product moving and eliminates hotspots: anchor scraper + counter-rotating beater scrape the entire kettle wall & floor.
- Electronic ignition (120 V)—no standing pilot means safer, more efficient starts.
- Seamless 304 SS liner & 304L jacket resist corrosion and are NSF approved for food contact.
- Full-body mineral insulation reduces radiant heat loss and lowers energy costs.
- 2" compression draw-off valve with 304 SS tube makes portioning and cleanup fast.
- Comprehensive safety suite: thermostat control, pressure relief, air eliminator, sight glass, low-water cutoff & indicator light.
- Made in the USA and built to ASME, NSF, UL, AGA & other applicable standards.
MV Mixer Performance
- Enclosed, balanced aluminum bridge with actuator-assisted lift for safe tilt-out access.
- Totally enclosed 2-speed gear motor (15 : 1 ratio) – High: 46 RPM / 120 RPM • Low: 23 RPM / 60 RPM (main / secondary).
- 304 SS anchor agitator contoured to the kettle; removable nylon blades continuously scrape.
- Counter-rotating secondary beater aerates and blends for uniform texture.
- Quick-release bayonet mounts let you remove both tools for cleaning without tools.
- Built-in safety lockout prevents high-speed starts when the bridge is raised.
Technical Specifications
| Capacity | 60 gal / 227 L |
|---|---|
| Heat Source | Natural or Propane gas, 106,800 BTU/hr |
| Steam Jacket | 2/3 jacketed, 304L stainless, ASME stamped |
| Temperature Range | 150 °F – 260 °F (65 °C – 127 °C) via thermostat |
| Ignition | Electronic spark, 120 V, 1 A (208/240 V optional) |
| Gas Connection | 3/4" IPS inlet (Nat 5–7" W.C. • LP 12–14" W.C.) |
| Agitator Motor | 2 HP (high) / 1 HP (low) totally-enclosed gear motor |
| Draw-Off Valve | 2" 304 SS compression type, removable perforated disc strainer |
| Interior Diameter (A) | 29.5" / 750 mm |
| Working Depth (B) | 25.0" / 635 mm |
| Overall Height, cover open (J) | 81.2" / 2062 mm |
| Clearance to Floor (S) | 20.9" / 531 mm |
| Construction | 304 SS kettle, outer casing, legs & seam-welded control console |
| Certifications | NSF, ASME, UL, CSA, ETL, AGA (varies by configuration) |
| Country of Origin | Made in Waynesboro, GA USA |
What’s in the Crate
- LGB-60 kettle with full insulation & control console
- MV twin-shaft agitator assembly (anchor, scraper blades, secondary beater)
- One-piece domed cover, actuator-assisted
- Perforated 1/4" disc strainer
- Factory testing & quality documentation
Need baskets, water faucets or a flexible spray hose? Legion offers a full range of factory-installed accessories—ask your rep for details before ordering.
