Legion LGB-60F Low-Profile 60 Gal. Self-Contained Gas Kettle with 2-Speed Mixer

Gas-Fired • Full Jacket • Made in the USA

Cook, mix and serve high-volume batches faster and safer with Legion’s Insulated-for-Safety™ LOW-RIM™ kettle system. The 60-gallon LGB-60F combines a seamless 304 stainless kettle, a powerful 2-speed twin-shaft agitator and a self-contained gas heating package—delivering even cooking, hands-free mixing and worry-free protection for your team.

Why You’ll Love It

  • Low-Profile, Easy Access: LOW-RIM™ design keeps the pouring lip within comfortable reach—no step stool required.
  • All-Stainless Construction: Seamless deep-drawn 304 liner, 304L full jacket, outer skin, legs and control console resist corrosion and clean up fast.
  • Self-Contained Gas Heat: 131,400 BTU burner, electronic ignition and full body insulation for quick heat-up and cooler kettle surfaces.
  • Integrated 2-Speed Mixer: Anchor-style agitator with nylon scrapers plus counter-rotating beater keep thick or delicate products moving to eliminate scorching.
  • Precision & Protection: Thermostat control (150 – 260 °F), pressure relief, low-water cut-off, sight glass and safety pilot safeguard every batch.
  • Fast, Clean Emptying: 2" compression draw-off valve and 304 stainless tube speed production change-overs.
  • Made in the USA & ASME/NSF Certified: Built to the toughest standards for lasting value in any commercial kitchen.

Built-In Twin-Shaft Agitator

  • Two operating speeds (Low: 23/60 RPM • High: 46/120 RPM main/secondary)
  • 304 stainless anchor agitator contoured to kettle wall
  • Nylon scraper blades continuously clean interior surface
  • Counter-rotating beater improves heat transfer and product consistency
  • Bayonet-mount tools lift out without tools for quick cleaning
  • Actuator-assisted bridge & tool lift with positive rim lock

Technical Specifications

Capacity 60 gal | 227 L
Heat Source Natural or Propane Gas  •  131,400 BTU/h
Temperature Range 150 °F – 260 °F (65 °C – 127 °C)
Kettle Construction Seamless 304 SS liner, 304L SS full jacket, deep-drawn radius lip
Outer Casing / Console 304 SS, seam-welded, full body insulation
Agitator Motor 2-speed gear motor (High 1½ HP / Low ¾ HP) 120 V, 1-ph
Draw-Off Valve 2" 304 SS compression type, sanitary design
Controls Electronic ignition, thermostat dial, indicator lights, pressure gauge, sight glass
Safety Devices Low-water cut-off, pressure relief valve, air eliminator, safety pilot
Gas Connection 3/4" NPT, Natural 5–7" W.C. • Propane 12–14" W.C.
Overall Dimensions* A 32.5" • B 22.3" • C 39.5" • F 44.1" • J 82.0"
*See spec sheet for complete dimensional drawing.
Certifications ASME, NSF, CSA & more

What’s Included

  • 60 gal LOW-RIM™ stationary kettle with full jacket & insulation
  • Mixer bridge, anchor agitator, secondary beater & scraper blades
  • Stainless domed cover (actuator-assisted)
  • Perforated 1/4" disc strainer
  • Adjustable bullet feet (4)
  • Owner’s manual & one-year limited warranty

Popular Options & Accessories

  • Single or dual faucets with swing nozzles
  • 48" flexible spray hose assembly
  • Automatic water fill meter
  • Gas quick disconnect or flexible gas hose
  • Basket inserts, measuring strip, draw-off hose & more

Need a custom configuration? Contact our product specialists for assistance.

Installation Notice: This appliance must be installed by qualified personnel in accordance with local codes. For full clearance and utility requirements, refer to the Legion installation manual.

Product Weight:

1205.0 lb
Manufacturer Legion
Shipping Weight 1205.0lbs
Capacity 60 gal
Kettle Liner stainless steel
Kettle Jacket full jacket
Base tri-leg
Type stationary
Specifications Low Profile Stationary Kettle, Gas, with mixer, self-contained, 60-gallon, 304 stainless steel liner, full jacket, thermostat temperature control, electric ignition, 2" compression draw-off valve, full body insulation, stainless steel kettle, legs & control console, 131,353 BTU
