Legion LGB-40MV Steam Kettles
Description
Legion LGB-40 Gas Stationary Kettle with Integrated Two-Speed Mixer – 40 gal
Self-Contained • 2/3 Jacketed • Insulated for SafetyBuilt for demanding production kitchens, the 40-gallon Legion LGB-40 pairs the speed of steam with the control of gas heat and the consistency of a twin-shaft agitator. Its deep-drawn 304 SS kettle, full-body insulation, and precise thermostat (150 – 260 °F) deliver perfectly even results batch after batch—without the need for an external boiler.
Key advantages
- Rapid, uniform heating from a 2/3 steam jacket wrapped in high-density insulation.
- Powerful two-speed mixer removes manual stirring and prevents scorching.
- Seamless 304 SS liner with sanitary radius lip for easy cleaning and smooth pouring.
- Electronic ignition and 79,900 BTU natural-gas burner (83,100 BTU propane option).
- 2″ compression draw-off valve handles thin broths to chunky stews with ease.
- Completely self-contained—no external steam, boiler, or condensate return required.
Kettle construction & safety
- Seamless deep-drawn 304 stainless steel kettle liner & 304L stainless jacket.
- Full-body insulation keeps exterior surfaces cool to the touch.
- Kettle protection package:
- Pressure relief & air eliminator valves
- Pressure gauge & sight glass
- Automatic low-water cut-off with indicator light
- Safety pilot control
- One-piece domed stainless cover with actuator assist.
- Stainless control console & four adjustable bullet feet for rock-solid floor mounting.
Integrated twin-shaft mixer
- Enclosed, balanced aluminum mixer bridge—tilts out for full kettle access.
- Totally enclosed gear motor with two operating speeds:
- Low: 23 RPM main agitator / 60 RPM secondary
- High: 46 RPM main agitator / 120 RPM secondary
- 304 SS anchor-style main agitator hugs kettle wall; nylon scraper blades wipe every inch.
- Counter-rotating 304 SS beater breaks up solids for consistent product texture.
- Bayonet-mount shafts remove in seconds for cleaning or kettle-only operation.
- Actuator-assisted lift plus positive rim-lock; safety device blocks high-speed starts when raised.
Technical specifications
| Capacity | 40 gal / 151 L |
|---|---|
| Heat source | Natural gas, 79,900 BTU hr (propane 83,100 BTU hr) |
| Gas connection | 3/4″ NPT (IPS) supply |
| Jacket coverage | 2/3 kettle height |
| Temperature range | 150 – 260 °F, thermostat controlled |
| Ignition | Electronic spark, 120 V, 1 A, 50/60 Hz |
| Draw-off valve | 2″ 304 SS compression type with perforated disc strainer (¼″ holes) |
| Kettle interior | 304 stainless steel, sanitary polish |
| Exterior & console | 304 stainless steel, seam-welded |
| Overall height | 77.5″ (cover open) |
| Kettle diameter | 25.5″ |
| Certifications | ASME, NSF, CSA |
What’s in the box
- Legion LGB-40 kettle with twin-shaft mixer
- Perforated disc strainer
- One-piece domed lid with lift assist
- Removable nylon scraper blades
- Operator manual & 12-month parts-and-labor warranty
Need faucet assemblies, rinse hoses, or basket inserts? Legion accessories are available to tailor your LGB-40 to any production flow.
