Legion LGB-40FMV Steam Kettles
Legion LGB-40FMV Steam Kettles is backordered and will ship as soon as it is back in stock.
This product is discontinued and no longer available for purchase.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Legion LGB-40FMV Steam Kettles
Description
Legion LGB-40F Low-Profile 40 Gallon Gas Kettle with 2-Speed Mixer
Self-Contained • Full Jacket • Insulated for Safety™Engineered for high-volume, scratch-cook operations, the Legion LGB-40F pairs a 40-gallon Low-Rim™ stationary kettle with a powerful twin-shaft MV mixer. Braise, simmer, sauté or hold with rock-solid temperature control while the agitator keeps product moving for even heating, reduced labor and scorch-free results.
Why You’ll Love It
- 40 gal / 151 L seamless, deep-drawn 304 stainless liner with sanitary radius lip
- Full 304L stainless jacket (50 psi) blanketed by Insulated for Safety™ body insulation
- Gas-fired burner delivers 106,800 BTU* with reliable 120 V electronic ignition
- Thermostatic 150 °F – 260 °F control plus safety pilot, low-water cut-off & pressure relief
- Factory-installed 2″ compression draw-off valve and ¼″ perforated disc strainer
- Twin-shaft MV mixer: anchor-style agitator with nylon scrapers & counter-rotating beater
- Two-speed gear motor (23 / 46 RPM) prevents hot spots and maintains product integrity
- Actuator-assisted bridge lift for effortless agitator removal & kettle access
- Low-Rim™ ergonomic height (≈ 34″ rim) simplifies loading, tasting & pan filling
- Seam-welded stainless legs with adjustable bullet feet for a rock-steady stance
- Made in the USA; meets or exceeds ASME, NSF, UL, AGA & CSA standards
At-a-Glance Specs
| Model | LGB-40F-MV |
|---|---|
| Capacity | 40 gal / 151 L |
| Heat Source | Natural or Propane Gas, 106,800 BTU/hr* |
| Temperature Range | 150 °F – 260 °F (thermostatic) |
| Electrical | 120 V, 1 ph, 1 A (ignition & mixer controls) |
| Mixer Speeds | Low 23 RPM / High 46 RPM |
| Agitator Motor | ¾ HP (low) / 1 HP (high) TEFC gear motor |
| Draw-Off Valve | 2″ compression, 304 stainless |
| Overall Dimensions ** | 41.1″ W × 35.0″ D × 74.5″ H |
| Shipping Weight | ≈ 890 lb / 404 kg |
*Propane input 108,500 BTU/hr.
**Height shown with mixer bridge raised; see spec drawing for complete clearances.
Perfect For
- Central & commissary kitchens
- Healthcare and correctional foodservice
- Soup, sauce, chili & oatmeal production
- Batch cooking for catering or meal-prep facilities
What’s Included
- Kettle with integrated mixer & stainless control console
- One-piece domed cover (actuator-assisted)
- ¼″ perforated disc strainer
- Owner’s manual & warranty registration
Covered by Legion’s 1-year parts & labor warranty; extended coverage available. Specifications subject to change without notice.
