Legion LGB-30MV Steam Kettles
Description
Legion LGB-30 Gas Stationary Kettle with Integrated Mixer – 30 Gal
Self-Contained • 2/3-Jacketed • Insulated for Safety™ • Made in USABoost batch throughput, cut labor and keep every ounce of product at the perfect temperature with Legion’s 30-gallon LGB-30 kettle. A seamless 304 stainless liner, full-body insulation and a heavy-duty twin-shaft mixer deliver reliable performance for high-volume soups, sauces, purées and more—right on the production floor.
Why You’ll Love It
- 66,725 BTU gas burner brings product to temperature fast and maintains a steady simmer.
- Twin-shaft, two-speed agitator (23 & 46 RPM) keeps even thick or delicate recipes uniform without scraping or scorching.
- 2/3 steam jacket surrounds the kettle wall for gentle, even heat from 150 °F – 260 °F (65 °C – 127 °C) controlled by an easy-set thermostat.
- Full body Insulated for Safety™ design keeps exterior surfaces cool and energy bills low.
- Seamless deep-drawn 304 liner with integrally formed radius lip cleans easily and resists pitting.
- 2″ compression draw-off valve plus perforated ¼″ disc strainer for clog-free portioning.
- Electronic ignition (120 V)—no standing pilot, just push-button starts.
- Built-in protection system: low-water cut-off, pressure relief valve, air eliminator & gauge.
- All-stainless exterior—legs, outer casing & seam-welded control console stand up to daily wash-downs.
Integrated Twin-Shaft Mixer
- Anchor-style main agitator hugs the kettle contour; removable nylon scrapers wipe the entire surface.
- Counter-rotating secondary beater breaks up lumps and accelerates heat transfer.
- Bayonet-mount shafts lift out in seconds for cleaning or when kettle is used without mixing.
- Actuator-assisted lift raises the agitator & bridge clear for safe loading and inspection.
- Safety interlock prevents high-speed starts when agitator is raised.
Technical Specifications
| Model / Capacity | LGB-30 • 30 gal (114 L) |
|---|---|
| Energy Source | Natural or Propane Gas |
| Input | 66,700 BTU/hr (Natural) • 67,800 BTU/hr (LP) |
| Gas Connection | ½″ NPT (IPS) supply |
| Operating Temp. Range | 150 °F – 260 °F (65 °C – 127 °C) |
| Ignition / Electrical | Electronic; 120 V, 1 Ph, 1 A |
| Draw-Off Valve | 2″ compression type, 304 SS |
| Overall Height (lid up) | ≈ 70.1″ (178 cm) |
| Footprint (A × C) | 23.0″ × 37.1″ (58 cm × 94 cm) |
| Construction | 304 SS liner, jacket, outer casing, legs & console |
| Compliance | ASME, NSF, CSA & others |
| Country of Origin | USA |
What’s in the Crate
- LGB-30 insulated self-contained kettle with twin-shaft mixer
- One-piece domed cover, actuator-assisted
- Perforated ¼″ disc strainer
- Adjustable bullet feet (pre-installed)
- Owner’s & installation manual
Need faucets, basket inserts or other accessories? Legion offers a full range of factory-installed and aftermarket options—contact us for details.
