Legion LGB-100 Gas Stationary Kettle with 2-Speed Mixer – 100 Gal.
Insulated • Self-Contained • 2/3-Jacketed • 154,836 BTUBuilt for high-volume kitchens that refuse to compromise on consistency or speed, the American-made Legion LGB-100 combines a 100-gallon deep-drawn stainless kettle with an integrated two-shaft agitator. The result is a self-contained cooking and mixing powerhouse that delivers uniform results, improved safety and lower utility costs—no external boiler required.
Key Advantages
- Massive capacity, minimal footprint – 100 gal. (379 L) stationary design handles your biggest batches without hogging floor space.
- True one-pot processing – Twin-shaft MV mixer (anchor + counter-rotating beater) keeps product uniformly blended while cooking.
- Deep-drawn 304 stainless liner – Seam-free interior with integrally formed radius lip for effortless cleaning and full sanitary compliance.
- Energy-saving full-body insulation – Keeps heat where it belongs and exterior surfaces cool to the touch.
- Self-contained steam jacket – 2/3 jacket generates its own steam; simply hook up gas and water—no boiler room needed.
- Electronic spark ignition – 120 V system eliminates standing pilots and improves ignition reliability.
- All-stainless exterior – Outer casing, control console, domed cover and legs are 100 % stainless for unmatched durability.
Integrated 2-Speed Agitator
- 304 SS anchor agitator shaped to kettle contour with removable nylon scraper blades.
- Counter-rotating secondary beater eliminates dead zones and accelerates heat transfer.
- Two-speed gear motor: 23 / 46 RPM main agitator | 60 / 120 RPM secondary beater.
- Actuator-assisted lift and positive rim-lock for fast tool changes and safe kettle access.
- High-speed start-up protection prevents accidental full-speed engagement.
Built-In Safety & Control
- Thermostat temperature control: 150 °F – 260 °F (66 °C – 127 °C).
- Pressure relief valve, air eliminator, pressure gauge & jacket sight glass.
- Automatic low-water cut-off with indicator light protects the jacket.
- Safety pilot gas control and electronic ignition reduce flame-out risk.
- 2″ 304 SS compression draw-off valve with perforated strainer for smooth portioning.
Technical Specifications
| Capacity | 100 gal. / 379 L |
|---|---|
| Heat Source | Gas-fired, 154,836 BTU (Natural) | 149,200 BTU (Propane) |
| Gas Connection | 3/4″ IPS, Supply pressure – Nat 5-7″ W.C. | LP 12-14″ W.C. |
| Electrical (Ignition) | 120 V, 1 Φ, 60 Hz, 1 A |
| Electrical (Mixer) | 115 / 208 / 230 / 460 V, 1 or 3 Φ, 60 Hz; 2 HP (High) | 1 HP (Low) |
| Jacket Type | Self-contained 2/3 steam jacket, 304L stainless |
| Temperature Range | 150 °F – 260 °F (66 °C – 127 °C) |
| Overall Height (cover open) | 92.4″ / 235 cm |
| Construction | 304 SS liner, jacket, outer casing, control console & cover |
| Standard Accessories | One-piece actuator-assisted domed cover, perforated disc strainer (¼″ holes), adjustable bullet feet |
Made in the USA by Legion Industries — Waynesboro, GA. Specifications subject to change without notice.
Product Weight:
1260.0 lbFrequently Asked Questions
