Legion  |  SKU: HEC-60MV

Legion HEC-60MV Steam Kettles


This product is discontinued and no longer available for purchase.

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Legion HEC-60 High-Output 60-Gallon Electric Stationary Kettle with Integrated Mixer

Model HEC-60 • 36 kW • Made in USA

Engineered for high-volume kitchens, the Legion HEC-60 pairs a 60-gallon self-contained, 2/3-jacketed kettle with a rugged twin-shaft mixer. Expect faster heat-up, consistent product movement and the durability of all-stainless construction—no external boiler required.

Kettle Highlights

  • Seamless deep-drawn 304 stainless liner with integral radius lip—sanitary & easy to clean.
  • 2/3 jacket delivers even, indirect steam heating over sidewalls and bottom.
  • High-output 36 kW electric elements (field-replaceable) for rapid batch times.
  • Thermostatic control 150 °F–260 °F (66 °C–127 °C) with low-water cut-off indicator.
  • Full body insulation improves energy efficiency & keeps exterior surfaces cooler.
  • 2" 304 stainless compression draw-off valve with 1/4" perforated disc strainer.
  • One-piece domed stainless cover, actuator-assisted for smooth, controlled lifting.
  • Four heavy-duty stainless legs with adjustable bullet feet for perfect leveling.

Integrated Two-Speed Mixer

  • Twin-shaft agitator: anchor-style main blade hugs the kettle contour for thorough scraping.
  • Counter-rotating secondary beater maximizes turnover and prevents hot spots.
  • Removable nylon scraper blades sweep the entire heated surface—no burn-on.
  • Two speeds: • Low 23 RPM for delicate products • High 46 RPM for thicker items.
  • Actuator-assisted bridge raises clear of the kettle for loading, sampling or cleaning.
  • Bayonet-mount agitator & beater detach in seconds—no tools required.
  • Safety interlock prevents high-speed starts when the bridge is lifted.

Operator Safety & Protection

  • ASME-stamped 304L stainless jacket with factory-set pressure relief valve.
  • Pressure gauge, air eliminator and manual jacket-water fill port standard.
  • Automatic low-water cut-off guards against element burnout.
  • Seam-welded stainless control console withstands daily wash-downs.

Specifications

Capacity 60 gal / 227 L
Heat Source Electric, self-contained 2/3 jacket
Power Rating 36 kW high-output
Temperature Range 150 °F – 260 °F (66 °C – 127 °C)
Electrical Options 208, 240, 380, 415, 440 or 480 V • 1- or 3-phase
Agitator Speeds Low 23 RPM / High 46 RPM (main shaft)
Draw-Off Valve 2" compression type, 304 stainless
Construction 304/304L stainless liner, jacket, outer casing & control console; full body insulation
Cover One-piece domed stainless, actuator-assisted
Certifications ASME, NSF, UL and other applicable approvals
Origin Waynesboro, Georgia USA

Popular Factory Options

  • Automatic water-fill meter
  • Single or dual rinse faucets with 12" or 18" swing nozzles
  • 48" flexible spray-hose assembly (vinyl or stainless)
  • 3" draw-off or ball-type valve
  • Tri-basket or nylon bag inserts for stocks & pasta
  • Lockable lid or control-console cover
  • Electric timer with buzzer

Need help selecting voltage, faucets or baskets? Our team will configure a Legion kettle package tailored to your production needs—just ask!

Features & Specs

Manufacturer

Legion

Shipping Weight

1200.0lbs

Type

stationary

Capacity

60 gal

Kettle Liner

stainless steel

Base

tri-leg

Jacket

2/3 jacket

Specifications

Stationary Kettle, Electric, with mixer, high output self-contained, 60-gallon, 304 stainless steel liner, thermostat temperature control, 2" draw-off valve, 2/3 jacket, full body insulation, stainless steel kettle, legs & control console, 36 kW
