Legion DSKL9-9 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker — Model DSKL9-9
Steam • Grill • Boil • Fry • Roast | Electric 21 kW | 40.1 gal CapacityReplace five single-purpose appliances with one powerhouse. The Legion Skittle® DSKL9-9 cooks up to nine hotel pans of product, holds 40 gallons of stock or 105 lb of frying oil, and tilts 10° for effortless pouring and clean-up. From breakfast scramble to evening stir-fry, this all-stainless workhorse keeps production high and floorspace low.
Key Features
- Five cooking modes in one footprint: steam, grill, boil, shallow-fry or roast.
- Accepts (9) 12" × 20" × 2-1/2" pans or (9) included stainless cooking baskets.
- 40.1 gal / 105 lb oil kettle handles high-volume batches with ease.
- Electric heating element — 21 kW for quick recovery, no boiler hookup required.
- 10° power-tilt pan and 1-1/2" compression draw-off valve speed product transfer.
- Patented insulated Capsule Lid with actuator-assist lift and adjustable steam vent.
- 304 stainless-steel, seam-welded pan body—insulated sides & bottom for energy savings and operator safety.
- 48" stainless spray hose with single ball valve simplifies wash-down.
- Heavy-duty tubular frame with adjustable flanged feet for code-compliant anchoring.
- NSF, UL, CSA & ASME compliant; Made in the USA.
Capacities at a Glance
| Cooking Mode | Batch Size |
|---|---|
| Steaming / Boiling | 9 hotel pans or 40.1 gal liquid |
| Frying | 105 lb shortening |
| Grilling / Sautéing | 1,029 in² cooking surface |
Technical Specifications
| Model | DSKL9-9 (leg-mounted, 10° tilt) |
|---|---|
| Heating | Electric, 21 kW |
| Total Capacity | 40.1 gal / 152 L |
| Oil Capacity | 105 lb / 47.6 kg |
| Pan Capacity | (9) 12" × 20" × 2-1/2" steam-table pans |
| Cooking Baskets | (9) perforated stainless baskets (included) |
| Pan Depth | 9 in (229 mm) |
| Draw-Off Valve | 1-1/2" compression type (other sizes optional) |
| Construction | All 304 stainless steel, seam-welded & insulated |
| Working Height | 31 in (787 mm) |
| Overall Footprint (W × D × H) | 41" × 54.3" × 74.3" (1,041 × 1,379 × 1,888 mm) |
| Certifications | ASME, NSF, UL, CSA |
Need faucets, automatic water fill or tamper-resistant hardware? Factory-installed options are available—ask your Legion representative for details.
What’s in the Box
- Legion Skittle® cooker with insulated Capsule Lid
- (9) stainless cooking/steaming baskets
- Cassette rack system for hotel pans
- 1-1/2" compression draw-off valve
- 48" flexible spray-hose assembly
- Adjustable flanged feet & mounting hardware
