Legion DSKL9-7 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® 9-Pan Multi-Function Cooker — 21 kW Electric
Steam • Grill • Boil • Fry • Roast • Sauté • Hold | Model DSKL9-7One footprint, endless versatility. The Legion Skittle® combines the power of a tilting kettle, griddle, steamer, fryer and oven in a single, heavy-duty station. Packed with 21 kW of electric performance and nine 12 × 20 × 2 1⁄2 in. pan positions, it is the ultimate production workhorse for high-volume kitchens that refuse to compromise on speed, yield or food quality.
Key Performance Benefits
- Multi-zone pan accepts 9 perforated or solid 12 × 20 pans for batch or à la carte cooking.
- Includes 9 stainless steel cooking baskets for effortless blanching, boiling and frying.
- 31.2 gal / 105 lb oil kettle capacity handles large batches without temperature drop.
- 10° powered tilt quickly drains product or transfers to hotel pans with minimal labor.
- 1 1⁄2 in. compression draw-off valve with tapered rim for clean, controlled dispensing.
- Patented Insulated for Safety™ capsule lid with actuator-assist and adjustable steam vent.
- 304 stainless steel, seam-welded construction — sanitary, durable and NSF compliant.
- 21 kW electric elements deliver rapid heat for searing, sautéing and recovery after loads.
- Factory-installed 48 in. flexible spray hose simplifies cleanup between menu changes.
- Made in the USA and rated for 125 psi (353°F) with integrated ASME safety valve.
7-in-1 Cooking Modes
- Steam or boil seafood, pasta and vegetables
- Grill & sear proteins directly on the 1,029 in² surface
- Fry up to 105 lb of oil for crisp chicken and fries
- Roast & bake with even convection-style heat
- Sauté, braise or simmer in kettle mode
- Hold foods at safe serving temperature
- Regeneration/finishing of pre-cooked items
Technical Specifications
| Cooking Surface | 1,029 in² (41 in W × 25 1⁄8 in D) |
|---|---|
| Pan Capacity | (9) 12 × 20 × 2 1⁄2 in. hotel pans / (9) SS baskets included |
| Kettle Volume | 31.2 gal (118 L) |
| Frying Oil Capacity | 105 lb (47.6 kg) |
| Power | 21.0 kW, 3 ph (field convertible); contact factory for other voltages |
| Tilt Angle | 10° front discharge |
| Working Height | 31 in. to rim |
| Draw-Off Valve | 1 1⁄2 in. compression, front-mounted |
| Operating Pressure | Max 125 psi / 353°F |
| Construction | All 304 stainless; insulated sides, bottom & lid |
| Footing | Adjustable flanged legs, floor mount |
| Country of Origin | USA |
Included With Your Skittle®
- (9) Perforated stainless steel cooking/steaming baskets
- Cassette rack system for standard 12 × 20 pans
- 48 in. stainless flexible spray hose & single ball valve
- Factory-installed safety valve and pressure gauge
- User & maintenance manual
Need specialty faucets, drain spouts or security options? Legion offers a full range of factory accessories to tailor the Skittle® to your operation. Contact us for details.
