Legion DSKL9-5 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker – 22.3 gal / 9-Pan Electric
Steam • Grill • Boil • Fry • Roast | 21 kW • 10° TiltReplace several single-purpose appliances with one powerhouse. The Skittle® combines a tilting kettle, griddle, steamer and fryer in a compact stainless-steel frame, letting you sear steaks at breakfast, boil pasta at lunch and deep-fry chicken at dinner—all without changing stations.
Why You’ll Love It
- Five independent cooking functions—steam, grill, boil, fry and roast—in one footprint-saving unit.
- 10° tilting pan design at a comfortable 31" working height for effortless loading, plating and cleaning.
- Insulated “Capsule” lid with actuator-assisted lift keeps heat in, energy costs down and operators safe.
- Adjustable steam vent and patented “L-shaped” condensate rim control moisture for perfect browning or gentle steaming.
- 1 ½" compression draw-off valve drains stocks, sauces or spent oil fast with no mess.
- Rugged 304 stainless-steel construction—seam-welded pan, tubular frame and component enclosure—built to thrive in high-volume kitchens.
- Flanged, height-adjustable feet bolt to the floor for code-compliant install and rock-solid stability.
At-a-Glance Capacity
| Pan capacity | (9) 12" × 20" × 2 ½" hotel pans (cassette rack included) |
|---|---|
| Cooking baskets | (6) stainless baskets for blanching, frying or portion control |
| Kettle volume | 22.3 gal (84 L) |
| Frying oil | 105 lb (47.6 kg) |
| Usable griddle area | 1,029 in² (0.66 m²) |
| Oven volume | 8.2 ft³ (0.23 m³) |
| Power | Electric, 21.0 kW total connected load |
| Operating pressure | Max 125 psi / 353 °F (safety valve included) |
Standard Inclusions
- 48" stainless-steel spray hose with single ball-valve control—perfect for rapid rinse-down.
- Cassette rack system accepts industry-standard steam table pans for batch production or mise-en-place.
- Comprehensive operator’s manual and Legion’s 12-month parts & labour warranty coverage.
Common Add-Ons (sold separately)
- Perforated or solid 12 × 20 pans—2 ½", 4" or 6" depths.
- Draw-off strainer, drain hose or spout for stocks and soups.
- Automatic water-fill meter for overnight kettle charging.
- Skittle care kit, fry scoops and #10-can holder.
Legion equipment is manufactured in the USA and complies with NSF, ASME and applicable local codes. Always verify utility requirements and clearances with your installer before purchase.
