Legion DSKL6-11 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker – Model DSKL6-11
Steam • Grill • Boil • Fry • Roast | 33.5 gal Kettle | 6-Pan CapacityConsolidate your kettle, griddle, fryer and holding cabinet into one labor-saving station. The Skittle® DSKL6-11 gives high-volume kitchens the flexibility to steam, grill, boil, fry and roast with a single 304-stainless workhorse that installs on a direct-steam line.
Why You’ll Love It
- True 6-in-1 performance – switch from 33.5 gal kettle work to 70 lb deep-fry in minutes.
- 10° power tilt and 31" working height for safe, ergonomic product transfer.
- Patented Insulated for Safety™ capsule lid with actuator-assist, “L” condensate catch and adjustable steam vent.
- Holds (6) 12" x 20" x 2½" hotel pans or (6) Legion cooking baskets on included cassette racks.
- 1½" compression draw-off valve plus 48" stainless spray hose accelerate cleanup and product draining.
- All-welded 304 stainless frame, enclosure and food-contact zone – built for decades of service.
- Rated 125 psi / 353 °F with factory-set safety valve for worry-free, code-compliant operation.
- Adjustable flanged feet bolt down fast for rock-solid stability.
- Made in the USA; conforms to ASME, NSF and other major agency standards.
At-a-Glance Specs
| Model | DSKL6-11 (Leg-Mounted, Direct Steam) |
|---|---|
| Cooking Modes | Steam, Grill, Boil, Fry, Roast, Hold |
| Insert Pans | (6) 12" × 20" × 2½" GN 1/1 |
| Cooking Baskets | (6) heavy-duty stainless baskets included |
| Kettle Capacity | 33.5 gallons (126.8 L) |
| Fryer Oil Capacity | 70 lb (31.8 kg) |
| Griddle Surface | 703 in² (4535 cm²) |
| Oven / Holding Volume | 8.2 ft³ (0.23 m³) |
| Pan Depth | 11" (280 mm) tilt pan |
| Draw-Off Valve | 1½" compression, 304 stainless |
| Operating Pressure | Max 125 psi / 353 °F |
| Exterior Material | All-welded 304 stainless steel |
| Overall Dimensions* | W 28.0" × L 34.0" × H 41.3" |
*Height shown with lid closed. Refer to cut-sheet for full dimensional drawings.
Standard Inclusions
- Cassette rack system for rapid pan or basket loading/unloading
- Variable-position lid actuator (hands-free hold-open)
- Steam control ball valve (1")
- 125 psi safety relief valve
- 48" stainless spray hose with self-closing nozzle
- Component enclosure protects controls from splash and impact
Popular Factory Options
- Single or dual deck-mount faucets (12" or 18" swing nozzles)
- Automatic water-fill meter
- Perforated or solid hotel pans, baskets & fry scoops
- 1½", 2" or 3" ball-type draw-off with strainers, spouts or hoses
- Lockable control cover & tamper-resistant fasteners for correctional facilities
Skittle® is a registered trademark of Legion Industries, Inc. All data subject to change without notice – consult current specification sheet for exact ratings and clearances.
