Description
Legion Skittle® Multi-Function Cooker – Model DSK15-9
Steam • Grill • Boil • Fry • Roast — 40 gal / 15-pan powerhouseReplace multiple pieces of equipment with one ultra-versatile, USA-made workhorse. The Skittle® handles high-volume production while saving space, energy, and labor.
Why Chefs Love the Skittle®
- Five true cooking modes: direct steam, grilling, boiling, frying, and roasting.
- Holds (15) 12" × 20" × 2-1/2" hotel pans or up to 12 cooking baskets at once.
- 40.1 gal kettle and 105 lb oil reservoir conquer soups, sauces, and deep-fried favorites.
- 10° powered tilt for smooth, controlled pour-off—even with the lid partially closed.
- Patented insulated Capsule Lid with adjustable steam vent keeps heat in and operators safe.
- All-304 stainless, seam-welded construction resists corrosion and cleans up fast.
- 1-1/2" compression draw-off valve with tapered rim for drip-free transfers.
- Single ball-valve rinse system with 48" stainless spray hose slashes clean-up time.
- Insulated sides & bottom reduce energy loss and keep exterior surfaces cool to the touch.
- NSF & ASME compliant; factory-set 125 psi safety valve for peace of mind.
At-a-Glance Specs
Model | DSK15-9 (Skittle®) |
---|---|
Cooking modes | Steam, grill, boil, fry, roast |
Pan capacity | (15) 12" × 20" × 2-1/2" pans |
Basket positions | 12 |
Kettle volume | 40.1 gal / 152 L |
Oil capacity (fry) | 105 lb / 47.6 kg |
Griddle surface | 1,029 in² / 6,635 cm² |
Oven/roast volume | 13.7 ft³ / 0.39 m³ |
Tilt angle | 10° |
Working height | 31" (front rim) |
Operating pressure | Up to 125 psi (353 °F) |
Draw-off valve | 1-1/2" compression (2" & 3" optional) |
Overall size (W × D × H) | 52.5" × 47" × 40"* |
Construction | All 304 stainless; insulated lid, sides & bottom; tubular frame |
Origin | Made in the USA |
*Height shown to pan rim; allow clearance for lid and tilt arc.
What’s Included
- Cassette rack set for 12" × 20" pans
- 48" stainless flexible spray hose assembly
- Adjustable flanged feet for secure floor mounting
- Factory-installed 125 psi safety valve
- Legion 12-month parts & labor warranty
Popular Accessories (sold separately)
- Perforated or solid hotel pans — 2-1/2", 4", 6" deep
- Perforated cooking/steaming baskets
- Single or dual rinse faucets with 12" or 18" swing nozzles
- Automatic water-fill meter
- Draw-off strainer, drain hose, or nut-driver tool
- Flat-bottom & fry scoops, Skittle® care kit
