Legion DSK15-5 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker – Model DSK15-5
Steam • Grill • Boil • Fry • Roast • Oven-FinishReplace six pieces of equipment with one. The Skittle® is an insulated, 10°-tilt direct-steam cooker that seamlessly moves from rapid steaming to high-temperature frying and roasting—all inside a 304 stainless-steel, NSF-listed cabinet that’s built in the USA.
Why chefs choose the Skittle®
- True multi-function performance—steam, grill, boil, fry, roast or bake in a single vessel.
- 10° powered tilt lets you drain, plate or clean with minimal lifting.
- Patented Capsule Lid with actuator assist, insulated sides/top and a fully adjustable steam vent for moisture control.
- Factory-installed cassette racks hold up to fifteen 12 × 20 × 2.5″ hotel pans or twelve perforated cooking baskets at once.
- Heavy-gauge 304 stainless-steel pan body—seam-welded, insulated on all sides and bottom.
- 1 ½″ compression draw-off valve plus 48″ stainless flex-hose spray for fast draining and cleanup.
- Adjustable flanged feet anchor securely to the floor for high-volume, high-traffic kitchens.
- Insulated for Safety™ construction keeps exterior temperatures low and energy use efficient.
- Certified to ASME, NSF and other applicable standards.
- Made, assembled and tested in Waynesboro, GA, USA.
Performance at a glance
| Pan capacity | (15) 12 × 20 × 2.5″ hotel pans |
|---|---|
| Basket capacity | (12) cooking/steaming baskets |
| Kettle volume | 22.3 gal / 85 L |
| Frying oil capacity | 105 lb / 47.6 kg |
| Oven volume | 11.3 ft³ / 0.32 m³ |
| Cooking surface | 1,029 in² (47 × 22″) |
| Operating pressure | Direct steam, max 125 psi / 353 °F (safety valve protected) |
| Draw-off valve | 1 ½″ compression, front-mounted |
| Working height | 31″ to cooking rim |
| Construction | Seam-welded 304 SS pan, frame & component enclosure |
Standard features
- Capsule Lid with “L” condensate containment and position lock.
- Steam control via 1″ ball valve.
- 48″ stainless spray hose with single ball valve shut-off.
- Safety valve (125 psi) and steam pressure gauge.
- Tapered access rim for easy ladling and reduced splash.
- Flanged, height-adjustable floor anchors.
- Fully insulated sidewalls, bottom and lid for operator safety.
Popular accessories (sold separately)
- Perforated or solid 12 × 20 pans – 2.5″, 4″ or 6″ deep
- Perforated steaming baskets (11″ × 20.5″ × 5″)
- Single or dual rinse faucets with 12″ or 18″ swing nozzles
- Automatic water-fill meter
- Draw-off strainers, drain hose & spouts
- Skittle® Care Kit and flat-bottom or fry scoops
Covered by Legion’s 12-month parts & labor warranty from date of installation. Extended coverage available—see Legion Industries for details.
