Legion DSK10-9 Skittle Braising Pans & Tilt Skillets

Legion Skittle® DSK10-9 Direct-Steam Multi-Function Cooker

Turn one footprint into an entire cookline. Built in the USA from seam-welded 304 stainless steel and insulated for operator safety, the Skittle® combines a tilting kettle, griddle, fryer, steamer, and roasting oven in a single, easy-to-clean vessel—perfect for high-volume kitchens that refuse to compromise on versatility or throughput.

Key performance benefits

• True multi-function capability: poach, blanch, braise, griddle, shallow/deep fry, roast & hold.
• Roomy 27.4 gal / 70 lb oil capacity handles 100+ portions per batch.
• Accepts up to ten 12″ × 20″ × 2.5″ hotel pans or eight full-size cooking baskets (included).
• 10° forward tilt plus 1.5″ compression draw-off valve for safe, mess-free product transfer.
• Patented capsule lid with actuator-assist, adjustable steam vent & “L” condensate catch.
• Maximum operating pressure 125 psi (353 °F) with factory-installed safety valve.
• Built-in 48″ stainless spray hose speeds change-overs and cleanup.
• Adjustable flanged feet anchor securely while leveling on uneven floors.

Model DSK10-9 specifications

What’s in the box

• (8) stainless perforated cooking/steaming baskets
• (2) cassette racks for hotel pans
• 48″ stainless flexible spray hose
• Factory-installed pressure safety valve & gauge
• User manual & 12-month parts-and-labor warranty

Need automatic water fill, dual faucets, or tamper-resistant hardware? Contact us for factory-installed options and accessories.
