Legion DSK10-7 Skittle Braising Pans & Tilt Skillets
Description
Legion Skittle® Multi-Function Cooker – Model DSK10-7
Steam • Grill • Boil • Fry • RoastReplace five separate pieces of equipment with one rugged, USA-built workhorse. The Legion Skittle® combines direct-steam speed, a patented insulated capsule lid and a gentle 10° tilt, giving high-volume kitchens unmatched versatility in the footprint of a single chassis.
Key Features
- Five independent cooking modes for maximum menu flexibility.
- 21.3 gal kettle / 70 lb oil capacity handles (10) 12 × 20 × 2 ½" pans or (8) baskets per batch.
- Direct-steam heated, seam-welded 304 SS pan recovers heat instantly.
- Patented insulated Capsule Lid with actuator-assist lift & adjustable steam vent captures condensate and saves energy.
- Ergonomic 10° forward tilt places the pan at a 31" working height for safe loading and plating.
- 1 ½" compression draw-off valve for quick, controlled stock or oil draining.
- 48" stainless spray-rinse hose with ball valve quick-cleans the pan between batches.
- Insulated sides & bottom keep exterior surfaces cool and reduce operating costs.
- Heavy-duty flanged feet bolt to the floor for code-compliant stability.
- NSF & ASME certified to 125 psi (353 °F) for dependable, long-term service.
Performance & Capacity
| Working depth | 7" (178 mm) |
|---|---|
| Hotel pan capacity | (10) 12 × 20 × 2 ½" pans |
| Basket capacity | (8) cooking / steaming baskets |
| Griddle surface | 703 in² (4 540 cm²) |
| Kettle volume | 21.3 gal (80.6 L) |
| Fryer oil | 70 lb (31.8 kg) |
| Roast/oven volume | 8.5 ft³ (0.24 m³) |
| Max operating pressure | 125 psi / 353 °F |
| Draw-off valve | 1 ½" 304 SS compression type |
Engineered for the Rush
- Seam-welded 304 SS frame and component enclosure resist harsh chemicals.
- Tapered rim and insulated lid virtually eliminate escaping steam.
- Rear/left utility connections keep the front and right sides clear for workflow.
- Field-adjustable flanged feet level the unit on uneven floors.
Popular Accessories (sold separately)
- Perforated or solid food pans – 2 ½", 4" & 6" deep
- Perforated cooking/steaming baskets (11" × 20 ½" × 5")
- Automatic water-fill meter kit
- Draw-off hose, spout or strainer
- Single or dual swing-spout faucet kit with bracket
- Skittle® care kit & fry scoop
Warranty
Covered by Legion’s 12-month parts & labor warranty from installation (15 months from ship date).
Looking for a larger or smaller capacity? Other Skittle® models range from 15 gal / 105 lb oil up to 49 gal / 14.9 ft³. Contact us for details.
