Description

Legion Skittle® Multi-Function Cooker

Model DSK10-5  |  Direct Steam  |  10° Tilting  |  15.2 gal

Steam, grill, boil, fry and roast—all in one footprint. Built for high-volume kitchens that refuse to compromise on speed or quality, the American-made Skittle® delivers unmatched versatility, rugged 304-stainless construction and industry-leading safety features.

Key Benefits

  • 5-in-1 performance: switch from steaming seafood to frying chicken to simmering soups without changing stations.
  • Handles 10 full-size (12 × 20 × 2-1/2") pans or 8 perforated baskets for maximum menu flexibility.
  • 15.2-gallon kettle and 70-lb oil well support batch cooking & high-throughput service.
  • Patented Capsule Lid is insulated, actuator-assisted and features an adjustable steam vent for precise moisture control.
  • 10° manual tilt plus a 1-1/2" compression draw-off valve make draining and portioning safe and fast.
  • Seam-welded, fully insulated 304-SS pan, lid and frame reduce energy loss and keep operators safe.
  • Rated for up to 125 psi / 353 °F direct steam; factory-installed safety valve protects your staff and equipment.
  • 48" stainless spray hose streamlines clean-down right at the station.
  • Adjustable flanged feet anchor the unit securely to meet code.
  • Proudly made in the USA to NSF, ASME and other leading agency standards.

Technical Specifications

Model DSK10-5 (Skittle®)
Cooking functions Steam, Grill, Boil, Fry, Roast
Pan capacity 10 × 12" × 20" × 2-1/2" pans
Basket capacity 8 stainless cooking/steaming baskets
Kettle volume 15.2 gal (57.5 L)
Frying oil 70 lb (31.8 kg)
Griddle surface 703 in² (4 535 cm²)
Tilt angle 10° manual
Max. steam pressure 125 psi / 353 °F (8.6 bar / 178 °C)
Draw-off valve 1-1/2" 304-SS compression type
Working height 31" (790 mm)
Construction Seam-welded & insulated 304 stainless steel
Footprint (approx.) 28" W × 34" D
Utilities Direct steam inlet & condensate outlet – 1" NPT

What’s Included

  • Skittle® Multi-Function Cooker with Capsule Lid
  • Cassette rack for 10 full-size pans
  • (8) perforated cooking/steaming baskets
  • 48" stainless spray hose assembly
  • User & installation manual

Optional Accessories

Sold separately—contact us for pricing and lead times.

  • Single or dual fill faucets with 12" or 18" swing nozzles
  • Automatic water-metering system
  • Perforated or solid pans (2-1/2", 4" or 6" deep)
  • Draw-off strainers, spouts & hoses
  • #10 can holder, flat-bottom scoop & fry scoop
  • Skittle® care & maintenance kit
  • Steam trap kits (standard or bright nickel-plated finish)
Installation note: This unit requires a dedicated direct-steam supply (up to 125 psi) and must be bolted to a level floor. Verify utilities and local code compliance before ordering.

Warranty: 12 months parts & labour from date of installation. Extended coverage available.

Features & Specs

Manufacturer

Legion

Brand_name

Skittle

Shipping Weight

495.0lbs

Controls

thermostatic controls

Pan Capacity

(10) 12" x 20" x 2.5"

Capacity

(1) 15.2 gal

Construction

stainless steel

Specifications

Skittle® Multi-Function Cooker, Steam/Grill/Boil/Fry/Roast, Direct Steam, 10° tilt, capacities: (10) 12"x20"x2-1/2" pan, (8) cooking baskets, 15.2 gallon kettle/70 pound oil, adjustable steam vent, 1-1/2" draw-off valve, stainless steel construction, flanged feet
