Legion DCS41-9 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® DCS41-9 Tilting Skillet – 40 Gallon Direct Steam
Insulated for Safety™ • Made in USAReplace multiple pieces of cooking equipment with one rugged, high-volume workhorse. The 40-gallon Legion Combi-Pan® delivers kettle, griddle, steamer and fryer performance in a single, compact tilting skillet engineered for speed, safety and simplicity in the busiest kitchens.
Key Advantages
- 40.1 gal (151 L) capacity - ideal for up to 380 soup or sauce servings per batch.
- Direct-steam heated 304 SS pan reaches temperature fast and recovers instantly between loads.
- 10° smooth tilt lets one operator pour or clean effortlessly.
- Patented actuator-assisted lid counterbalance prevents slams and burns.
- Insulated sides & bottom plus full-width condensate drip shield keep heat in the pan and off your crew.
- 1½ in compression draw-off valve with food-pan holder speeds straining and portioning.
- Approved for use as a fryer — 1,029 in² surface holds 105 lb of oil for high-output browning.
- Open tubular frame with flanged front feet & bullet rear feet anchors securely on uneven floors.
- All food-contact and structural components are heavy-gauge 304 stainless steel for exceptional hygiene and service life.
Specification Sheet
| Model | DCS41-9 (Leg Mounted) |
|---|---|
| Pan Capacity | 40.1 gal / 151 L |
| Pan Interior (W × Depth) | 41 in × 9 in |
| Cooking Surface Area | 1,029 in² |
| Frying Oil Capacity | 105 lb |
| Oven Volume | 5.4 ft³ |
| Tilt Angle | 10° manual crank |
| Working Height | 31 in |
| Steam Connection | 1 in NPT – direct steam, 125 psi max |
| Steam Control | 1 in ball valve |
| Safety Valve | Factory set, 125 psi |
| Draw-off Valve | 1½ in compression (2 in or 3 in ball valve optional) |
| Lid | 304 SS, actuator-assisted counterbalance, full-width steam vent & drip shield |
| Construction | Seam-welded 304 SS pan & frame, insulated sides/bottom |
| Feet | Adjustable flanged front, bullet rear (optional flanged rear or casters) |
| Approvals | ASME, NSF & others |
| Country of Origin | USA |
Popular Options & Accessories
- Single or dual 48 in spray-hose / fill-faucet assemblies
- Automatic water-filling meter
- Perforated or solid 12 × 20 in food pans (2 ½ in, 4 in or 6 in deep)
- Perforated cooking / steaming baskets (11 × 20½ × 5 in)
- Draw-off strainer, drain hose or spout extensions
- #10 can holder, flat-bottom scoop, fry scoop, 3-part cleaning tool
- Security kits: lockable lid & control cover, tamper-proof fasteners
- Casters & restraining devices for mobile installations
Need a different capacity? Legion Combi-Pans are available from 15 gal to 62 gal. Contact our team for a custom quote.
