Legion DCS41-7 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® Insulated Tilting Skillet – 31.2 gal / 10° Tilt
Direct-Steam, Leg-Mounted • Model DCS41-7Built for demanding commercial kitchens, the Legion Combi-Pan® combines the throughput of a braising pan, tilt skillet and shallow fryer in one rugged steam-heated unit. A generous 31.2-gallon (118 L) capacity and insulated 304 stainless pan let you sear, simmer, fry or hold large batches with outstanding heat transfer and operator safety.
Standard Features
- Direct-steam heated 304 SS pan for rapid, even cooking—no burners or heating elements to service.
- 10° manual tilt with positive stop for safe, controlled product transfer.
- Actuator-assisted, counterbalanced lid featuring full-width condensate drip shield & adjustable rear steam vent.
- Insulated sides and bottom (Insulated for Safety™) keep exterior surfaces cool and cut energy loss.
- 1 ½" compression draw-off valve with food-pan holder and rear drip collector.
- Open, seam-welded 304 SS tubular frame; 31" working height for ergonomic access.
- Adjustable flanged front feet & bullet rear feet for a secure, level installation.
- Approved for use as a shallow fryer—handles up to 105 lb of oil with optional fryer kit.
- Made in the USA and backed by Legion’s 12-month parts & labor warranty.
At-a-Glance Specifications
| Model | DCS41-7 |
|---|---|
| Capacity | 31.2 gal (118 L) |
| Cooking Surface Area | 1,029 in² (0.66 m²) |
| Pan Inside Dimensions (W × L × D) | 41" × 38" × 7" |
| Tilt Angle | 10° manual |
| Draw-Off Valve | 1.5" compression, 304 SS |
| Steam Connections | 1" NPT inlet & outlet • Safety valve: 125 psi |
| Working Height | 31" |
| Construction | 304 SS pan, lid, component enclosure & tubular frame |
| Overall Width (F) | 40" |
| Overall Depth (C) | 38" |
| Overall Height (J) | 70.8" |
Popular Accessories (sold separately)
- Single or dual ball-valve fill faucets with 48" flexible spray hose.
- Perforated cooking/steaming baskets & 12 × 20 food pans (2.5", 4" or 6" deep).
- Draw-off strainers, drain hose & drain spout.
- Lockable lid and control cover for correctional installations.
- Casters & restraining device kit for mobile applications.
Standard warranty: 12 months from installation (15 months from ship date). Extended coverage available.
