Legion DCS41-5 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® 22.3-Gallon Direct Steam Tilting Skillet
Model DCS41-5 | Made in USAReplace your braising pans, kettles, griddles and fryers with one ultra-versatile workhorse. The 22.3-gallon Combi-Pan® Tilting Skillet delivers rapid, even heating via direct steam, while Legion’s Insulated for Safety™ construction keeps energy where it belongs—inside the pan, not in your kitchen.
Whether you’re simmering 80 litres of chowder, browning 40 kg of ground beef, or flash-frying up to 105 lb of chicken cutlets, this skillet’s 10° manual tilt and counterbalanced lid make loading, unloading and clean-up effortless.
Top Features
- 22.3 gal (84 L) capacity pan tilts a precise 10° for fast, controlled product transfer.
- 304 SS, seam-welded pan with full side & bottom insulation for operator safety and energy savings.
- Patented actuator-assisted lid with full-width condensate drip shield and rear steam vent.
- 1 ½″ compression draw-off valve plus built-in food-pan holder—ideal for draining stocks or portioning sauces.
- Adjustable steam vent gives you moisture control for perfect browning or gentle steaming.
- Open stainless frame with flanged front feet & bullet back feet for secure, level installation.
- 125 psi ASME safety valve and NSF/CSA approvals for worry-free compliance.
- Rated for shallow frying—handles up to 105 lb of oil.
At-a-Glance Specs
| Working Capacity | 22.3 gal / 84 L |
|---|---|
| Griddle/Cooking Area | 1,029 in² |
| Pan Depth | 5 in (127 mm) |
| Tilt Mechanism | Manual, 10° with positive stop |
| Heat Source | Direct steam (1″ NPT inlet & outlet) |
| Safety Valve | 125 psi ASME-certified |
| Draw-Off Valve | 1 ½″ compression (2″ or 3″ available) |
| Working Height | 31 in (787 mm) |
| Overall Width | 53 in (1,346 mm) |
| Overall Depth | 36 in (914 mm) |
| Construction | 304 stainless pan, lid, frame & enclosure—fully seam welded |
| Approvals | NSF, ASME, CSA |
Perfect For
- Bulk soups, sauces & chili
- Braising meats & vegetables
- Scrambled eggs or pasta for banquets
- Shallow-frying cutlets, fries or tofu
- High-output griddle items like pancakes, quesadillas & burgers
Optional Accessories
- 48″ flexible spray hose (vinyl or stainless)
- Perforated cooking/steaming baskets (11″ × 20 ½″ × 5″)
- Draw-off strainer, drain hose or spout
- Lockable lid and control cover for security installations
- Caster & restraining-device kit for mobile setups
Specifications listed are nominal and subject to change without notice. Performance may vary with product load, density and fill level.
