Legion DCS41-14 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® 62.4-Gallon Direct Steam Tilting Skillet
Model DCS41-14 • Made in the USAEngineered for high-volume culinary production, the insulated Combi-Pan® delivers the power of a tilting skillet, braising pan, kettle, griddle and fryer— all in one rugged, 100 % stainless-steel unit. A smooth 10° tilt, counter-balanced safety lid and 1 ½″ draw-off valve make batch cooking, portioning and clean-up faster and safer than ever.
Highlights
- 62.4 gal (236 L) working capacity—our largest round pan
- Direct-steam heated, insulated sides & bottom for energy savings and a cooler kitchen
- 10° manual tilt with seamless pan lip for smooth, drip-free pouring
- Patented actuator-assisted lid with full-width condensate drip shield & rear steam vent
- 304 SS 1 ½″ compression draw-off valve plus under-pan food-pan holder
- Approved for frying; handles up to 105 lbs of oil
- Open tubular frame with adjustable flanged front feet & bullet rear feet for easy leveling
- Built to ASME, NSF & other applicable standards
Standard Features
- 304 stainless, seam-welded food contact zone & pan body
- 31″ ergonomic working height
- Rear drip collector and tapered access rim to keep floors dry
- Steam control via 1″ ball valve; factory-set 125 psi safety valve
- Dual side-mounted safety handles on lid
- Seam-welded stainless component enclosure protects plumbing & controls
Specifications
| Capacity | 62.4 gal / 236 L |
|---|---|
| Pan interior (Ø × Depth) | 41″ Ø × 14″ D (104 cm × 35.6 cm) |
| Tilt angle | 10° manual, gear-assisted |
| Working height | 31″ (78.7 cm) |
| Draw-off valve | 1 ½″ 304 SS compression type (std.) |
| Frying oil capacity | 105 lbs (47.6 kg) |
| Oven volume | 8.4 ft³ (0.24 m³) |
| Overall dimensions* | Approx. 53″ W × 45″ D × 77.8″ H |
| Construction | 304 SS insulated pan & frame, seam welded |
| Steam connection | 1 NPT inlet / outlet (rear) |
| Agency approvals | ASME, NSF & others |
*Dimensions shown for the standard 1 ½″ draw-off valve configuration. Contact us for 2″ or 3″ valve dimensions or for optional faucet/spray-hose assemblies.
Popular Accessories (sold separately)
- Perforated or solid 12 × 20 food pans (2 ½″, 4″ or 6″ deep)
- Perforated cooking/steaming basket (11″ × 20 ½″ × 5″)
- 48″ flexible spray hose assembly (vinyl or stainless)
- Automatic water-filling meter
- Draw-off strainers, drain spouts & hoses
- Lockable lid & control covers (security models)
- Caster kit with restraining device for mobile installation
