Legion DCS28-9 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® DCS28-9 Direct-Steam Tilting Skillet
27.4 gal • 703 in² cooking surface • Insulated for Safety™Engineered for high-volume, multi-method cooking, the Combi-Pan® DCS28-9 combines the power of a kettle, griddle, braising pan and fryer in one space-saving unit. Its 304 stainless construction, full-body insulation and patented safety lid deliver dependable performance and operator protection shift after shift.
Why You’ll Love It
- 27.4-gallon capacity handles up to 70 lb of fry oil or 3.7 ft³ of oven volume for bulk production.
- Direct-steam heating provides rapid heat-up and precise control via a 1" steam ball valve.
- 10° quick-tilt pan at a 31" working height for fast, strain-free pouring and cleaning.
- Patented actuator-assisted lid with full-width drip shield and rear steam vent—opens smoothly, stays put.
- 1 ½" compression draw-off valve lets you portion stocks or drain fry oil without lifting heavy loads.
- Fully insulated sides & bottom retain heat and keep the exterior cool to the touch.
- 304 stainless open frame with flanged front feet and bullet back feet for rigid, code-compliant anchoring.
- NSF, ASME & UL compliant; approved for use as a fryer—true all-in-one versatility.
- Made in the USA and backed by Legion’s 12-month parts & labor warranty.
Built for Demanding Kitchens
- Institutional batch cooking—soups, sauces, stews, beans and chili
- High-volume skillet work—searing, browning and braising up to 703 in² at once
- On-demand frying—chicken, cutlets or tempura with 70 lb oil capacity
- Light baking or holding with the 3.7 ft³ oven cavity
At-a-Glance Specs
| Model | DCS28-9 (Combi-Pan® Series) |
|---|---|
| Capacity | 27.4 gal kettle / 70 lb fry oil / 3.7 ft³ oven volume |
| Cooking Surface | 703 in² (28" W interior) |
| Pan Depth | 9" |
| Heat Source | Direct Steam, 1" control ball valve |
| Tilting Angle | 10° manual tilt |
| Working Height | 31" |
| Draw-Off Valve | 1 ½" compression type |
| Lid | Actuator-assisted, full-width condensate shield & rear vent |
| Construction | 304 SS pan, lid, frame & enclosure; insulated sides/bottom |
| Safety Valve | 125 psi ASME-approved |
| Footing | Adjustable flanged front feet, bullet back feet |
| Certifications | NSF, UL, ASME |
| Country of Origin | USA |
Popular Factory Options
- 48" flexible spray hose (single or dual fill)
- Perforated cooking/steaming baskets (11" × 20 ½" × 5")
- Draw-off strainer or drain hose
- Automatic water-fill meter
- Lockable lid & control cover for correctional facilities
- Rear caster kit with restraining device
Covered by Legion’s 12-month parts & labor warranty (registration required). Extended coverage available—ask your product specialist.
