Legion DCS28-5 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® Direct Steam Tilting Skillet – 15.2 gal
Model DCS28-5 | 10° Tilt | Insulated for Safety™ | Made in USAReplace multiple pieces of equipment with one powerhouse. The Legion Combi-Pan® is a direct-steam, leg-mounted tilting skillet that braises, griddles, sautes, steams, fries and holds foods in a single 15.2-gallon vessel—while keeping your kitchen cooler, safer and more productive.
Why You’ll Love It
- 15.2 gal (57.5 L) capacity—perfect for small to mid-size batch production
- 10° precision tilt with tapered rim for smooth, splash-free pouring
- Direct steam heating through a 1″ steam control ball valve for lightning-fast recovery
- 304 SS food contact zone, seam-welded pan & tubular frame—built to last a lifetime
- Fully insulated sides & bottom to keep heat in the pan and energy costs down
- Patented actuator-assisted lid with full-width drip shield & rear steam vent
- 1 ½″ compression draw-off valve plus integrated food-pan holder for mess-free draining
- 31″ ergonomic working height and rear drip collector for a cleaner station
- Adjustable flanged front feet & bullet rear feet for a rock-solid, code-compliant install
- NSF, ASME & CSA compliant—approved for use as a deep fryer (70 lb oil capacity)
Technical Specifications
| Model | DCS28-5 |
|---|---|
| Kettle Capacity | 15.2 gal / 57.5 L |
| Pan Internal Depth | 5 in (127 mm) |
| Cooking Surface Area | 703 in² (4 534 cm²) |
| Tilt Angle | 10° manual tilt |
| Working Height | 31 in (787 mm) |
| Draw-off Valve | 1 ½″ compression-type, 304 SS |
| Steam Inlet / Outlet | 1″ NPT |
| Safety Valve | 125 psi ASME |
| Oil Capacity (Fry Mode) | 70 lb / 31.8 kg |
| Oven Volume (Bake/Roast) | 2.0 ft³ (0.057 m³) |
| Construction | 304 SS seam-welded pan, lid, frame & component enclosure |
| Feet | Adjustable flanged (front), bullet (rear) |
| Certifications | NSF, ASME, CSA • U.S. Patents 5,553,531 & 5,964,145 |
Optional Accessories
- 48″ single ball-valve spray hose (vinyl or stainless)
- Automatic water-fill meter
- Perforated cooking/steaming baskets (11″ × 20 ½″ × 5″)
- Perforated or solid 12 × 20 food pans (2 ½″, 4″ or 6″ deep)
- Draw-off strainer, drain spout or drain hose
- Lockable lid & control cover for high-security installations
- Caster kit with restraining device
Need more capacity? Combi-Pan® models are available up to 62.4 gal. Contact us to configure the perfect skillet for your kitchen.
