Legion DCS28-11 Combi-Pan Braising Pans & Tilt Skillets
Description
Legion Combi-Pan® Direct Steam Tilting Skillet – 33 ½ Gal
Model DCS28-11 | Insulated for Safety™Replace multiple pieces of equipment with one powerhouse. The 33 ½-gallon Combi-Pan® gives you the versatility of a braising pan, kettle, steamer, fryer and oven in a single, space-saving footprint—perfect for high-volume kitchens that demand speed, safety and legendary Legion durability.
Key performance & safety benefits
- Rapid, even heating via direct steam—ideal for searing, simmering or deep-frying up to 70 lb of oil.
- 10° tilting pan lets operators pour or plate with minimal effort.
- Walls and bottom are fully insulated to keep heat in the food zone and out of the kitchen.
- Patented safety lid with actuator-assisted counter-balance and full-width condensate drip shield.
- 304 stainless-steel construction throughout—seam-welded, sanitary and made in the USA.
- 1 ½″ compression draw-off valve for quick, controlled draining of product or fryer oil.
- Integrated steam control (1″ ball valve) and 125 psi safety valve for worry-free operation.
- 31″ working height on a rigid open frame with flanged front & bullet rear feet—bolt down or level in minutes.
- NSF, ASME and other agency approvals; also approved for use as a fryer.
Recommended applications
- Batch soups, sauces & stews
- High-volume braising & sautéing
- Pan-frying proteins or vegetables
- Steaming rice, pasta or vegetables with optional baskets
- Scratch-made reduction & glazing
Technical specifications
| Capacity | 33.5 gal | 127 L |
|---|---|
| Cooking surface area | 703 in² | 4 544 cm² (28″ pan ID) |
| Pan depth | 11″ | 279 mm |
| Tilt angle | 10 degrees, manual lever |
| Working height | 31″ to rim |
| Draw-off valve | 1 ½″ compression type (standard) |
| Steam supply connection | 1″ NPT, direct steam |
| Safety valve | Factory set @ 125 psi |
| Construction | All 304 stainless—pan, lid, frame & enclosure |
| Feet / mounting | Adjustable flanged front feet, bullet back feet |
| Agency approvals | ASME, NSF & others |
| Country of origin | Made in the USA |
Popular factory-installed options
- 48″ flexible spray-hose assembly (single or dual-fill)
- Automatic water fill meter
- Perforated cooking / steaming baskets (11″ × 20 ½″ × 5″)
- Draw-off strainer, drain hose or spout
- Casters & restraining kit for mobile installations
- Lockable lid or control cover for security applications
Backed by Legion’s standard 12-month parts & labor warranty (15 months from ship date). Extended coverage available at time of purchase.
