Leer 3764401-13 Pallet-Load Ice Merchandiser, Indoor, 225 cu. ft., Solid Loading Doors, 111.5"W x 62.25"D x 96.5"H
- Product Type
- Pallet-load ice merchandiser
- Model Detail
- PL225 Auto Defrost Solid Doors - L250UAGPLL
- Application
- Indoor
- Capacity
- 225.0 cu. ft.
- Temperature Range
- 16°F to 24°F
- Defrost
- Automatic
Specifications
Description
The Leer 3764401-13 is an indoor pallet-load ice merchandiser with 225 cu. ft. of capacity, a 16°F to 24°F temperature range, and self-contained refrigeration.
- Loading: Full pallets load via a ramp sold separately.
- Doors: Two solid galvanized steel loading doors and two glass customer doors.
- Temperature management: Automatic defrost and intelligent electronic controls.
- Construction: All-steel construction with high-performance insulation and durable all-weather paint.
- Refrigeration: R290 refrigerant and a bottom-mounted, self-contained system.
Overall Dimensions:
111.5"W x 62.25"D x 96.5"HProduct Weight:
1380.0 lbPallet-load capacity
Provides 225 cu. ft. of capacity and supports loading full pallets via a ramp sold separately.
Solid loading doors
Includes two galvanized steel loading doors measuring 48.75 inches wide by 76.75 inches high.
Customer access doors
Includes two glass doors measuring 28 inches wide by 56 inches high for customers.
Temperature control
Operates within a 16°F to 24°F temperature range with intelligent electronic controls.
Automatic defrost
Provides automatic defrost operation.
Self-contained refrigeration
Uses a bottom-mounted, self-contained refrigeration system with R290 refrigerant.
All-steel construction
Features all-steel construction, high-performance insulation, and durable all-weather paint.
Electrical system
Uses a 3/4 HP system rated at 115V/60/1-ph and 13 amps.
