Lang Manufacturing (Middleby) R30S-ATF Electric Ranges
Description
Lang 30" Electric Restaurant Range – Full-Width Griddle / Standard Oven (14 kW)
Model R30S-ATF | cULus & NSF Listed | Made in the USABuilt for high-volume kitchens that never compromise on durability, the Lang R30S-ATF delivers a 30 inch, one-piece ¾" thick griddle up top and a powerful, easy-to-use standard oven below—everything wrapped in rugged 430 stainless steel and mounted on 4" casters for true roll-in convenience.
Top Reasons You’ll Love It
- 30" W × 24" D × ¾" thick steel griddle plate with snap-action controls for lightning-fast recovery.
- 2.75" full-front grease trough, rear & side splash plus pull-out spillage drawers keep your line spotless.
- Solid-state oven thermostat (150-450 °F) with 1-hour timer—accuracy you can taste.
- 3 rack positions; 1 chrome rack included for pans, sheet trays or hotel pans.
- Heavy-duty hinge-down door and aluminized steel cooking chamber built to take daily abuse.
- Factory-wired 3-phase, field convertible to 1-phase for 208 V or 240 V service.
- 430 stainless steel on all sides, 2" vented stub back & 1" cook-top back-stop protect surrounding equipment.
- Ships on 4" swivel casters (front two locking) for effortless cleaning and layout changes.
At-a-Glance Specs
| Griddle Plate | 30" W × 24" D × ¾" thick steel, snap-action temperature control |
|---|---|
| Oven Type / Capacity | Standard oven, 3 rack positions, 1 chrome rack included |
| Oven Temperature Range | 150-450 °F (solid-state thermostat) + 1-hour timer |
| Total Power | 14.0 kW |
| Electrical Options |
208 V 1-ph 67.3 A 240 V 1-ph 58.3 A 208 V 3-ph 41.7 A 240 V 3-ph 36.1 A |
| Exterior Dimensions (w/ 4" casters) | 30" W × 30" D × 38.2" H (762 × 762 × 970 mm) |
| Approx. Weight | Installed: 270-310 lb (123-141 kg) | Shipping: 320-412 lb (145-187 kg) |
| Construction | 430 stainless steel exterior, aluminized steel oven chamber, 4" casters |
| Certifications | cULus, NSF |
| Warranty | 2 years parts & labor (factory authorized service nationwide) |
Ideal Applications
- Diners & family restaurants needing all-day breakfast versatility.
- Cafeterias and institutions where reliability trumps downtime.
- Food trucks or ghost kitchens seeking a compact, electric-only cooking solution.
