Lang Manufacturing (Middleby) R30S-ATB Electric Ranges
Lang Manufacturing (Middleby) R30S-ATB Electric Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Lang 30" Electric Restaurant Range – Hot Top & French Plates
Model R30S-ATB | Standard Oven Base | 14 kW | cULus & NSF ListedBuilt in the USA for chefs who refuse to compromise, the Lang 30" electric range pairs a versatile hot-top / French-plate cook surface with a rugged, easy-to-clean standard oven. Perfect for high-volume restaurants, hotels and culinary schools that demand consistent results shift after shift.
Key Performance Benefits
- (1) 12" × 24" × 3/4" cast-iron hot top delivers even heat up to 850 °F—ideal for stock pots, sauces and searing.
- (2) 8" diameter heavy-duty French plates with individual infinite switches for precise simmer-to-sear control.
- Solid-state oven thermostat holds 150–450 °F and includes a 60-minute timer with audible alarm.
- Aluminized steel oven chamber with 3 rack positions; (1) chrome rack supplied.
- Full-width 2.75" front grease trough, drain and removable spillage drawers keep the cook-top clean and safe.
- Factory-wired 3-phase; field convertible to 1-phase at 208 V or 240 V for flexible installations.
Built-To-Last Construction
- Heavy-gauge 430 stainless steel exterior—fully insulated on six sides.
- 2" vented stainless steel stub back protects walls while saving valuable hood space.
- Hinge-down, heavy-duty oven door for dependable, repeated use.
- Four 4" swivel casters (front locking) for effortless cleaning and maintenance access.
Safety & Certifications
- cULus listed for electrical safety.
- NSF certified for sanitation.
- Backed by Lang’s 2-year parts & labor warranty.
Technical Specifications
Overall width | 30" / 762 mm |
---|---|
Overall depth | 30" / 762 mm |
Height (with 4" casters) | 38.2" / 970 mm |
Cook-top configuration | (1) 12" hot top & (2) 8" French plates |
Oven type | Standard – 3 rack positions, (1) chrome rack included |
Oven temperature range | 150 °F – 450 °F (65 °C – 232 °C) |
Timer | 60-minute with audible alarm |
Total power | 14.0 kW |
Electrical options | 208 V / 240 V 1Ø or 3Ø • 480 V 3Ø |
Full-load amps | 208 V 1Ø 67.3 A • 208 V 3Ø 41.7 A • 240 V 1Ø 58.3 A • 240 V 3Ø 36.1 A • 480 V 3Ø 18.1 A |
Shipping weight | Approx. 320 – 412 lb / 145 – 187 kg |
Certifications | cULus, NSF, Made in USA |
Looking to spread out the cost? Ask about Middleby Equipment Financing to turn this range into manageable monthly payments.
