Description
Lang® Marine Double-Deck Radiant Broiler – 36" Upright w/ Open Cabinet Base
Model CLB36C-2 | 440 V / 60 Hz / 3-Phase | 24 kWPurpose–built for cruise lines and other demanding marine galleys, this electric, double-deck broiler delivers the rugged build, fast recovery and deck-mount security you need to keep service running smoothly—whether you’re in calm seas or heavy swells.
Key Benefits
- Two independent broiling decks stack vertically to double output in the same 36 in. footprint.
- Incoloy-sheathed radiant rod elements provide even, flame-free heat ideal for marine ventilation systems.
- Each deck features separate front & rear HI/LO switches for precise zone control.
- Counter-balanced broiler racks roll out easily, offer 5 height positions and include removable drip trays for fast cleanup.
- Open stainless steel cabinet base keeps sheet pans, utensils or hotel pans right where you need them.
- Watertight, etched control panel and flanged bolt-down legs meet stringent cruise-line specs.
- All 304 stainless steel exterior & interior resists corrosion from salt air and daily wash-downs.
- Chimney design helps cool control panels while keeping spray and water out of the unit.
- cULus Marine & NSF listed for safety, sanitation and on-board electrical compliance.
At-a-Glance Specs
| Decks / Type | 2 decks, upright radiant broiler |
|---|---|
| Overall Dimensions (H × W × D) | 69.5 in × 36.0 in × 34.0 in (1765 × 914 × 864 mm) |
| Cabinet Base Clear Opening | 27 W × 16 H × 24 D in (686 × 406 × 610 mm) |
| Heating Elements | Enclosed tubular radiant rods, Incoloy sheath |
| Electrical Rating | 24.0 kW, 440 V, 60 Hz, 3-Phase |
| Nominal Amps / Line | L1 35.4 A | L2 35.4 A | L3 23.6 A |
| Clearances (Combustible) | Sides 14 in (356 mm) | Back 4 in (100 mm) |
| Shipping Weight | Approx. 780 lb (354 kg) |
| Certifications | cULus Marine, NSF |
Ideal For
- Cruise-line main galleys & lido-deck grills
- Offshore platforms & research vessels
- Naval, coast-guard & ferry kitchens
Included Warranty
Manufacturer’s limited 1-year parts & labor warranty (U.S. labor only). Additional international and extended-term coverage available—ask your rep for details.
