Lakeside Manufacturing 163422 Motorized Stainless Steel Utility Cart, 3-Tier, 1000-lb Capacity

SKU: 163422
$5,225.00
Free Shipping
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Lakeside Load-Master™ 163422 is a battery-operated, 3-tier utility cart with a 1,000 lb capacity and open design. Its motorized 24-volt transaxle drive provides forward and reverse operation with two handle-controlled speed settings.

  • Welded stainless steel construction with 14-gauge solid shelves
  • 24.5 in x 36 in shelf size
  • Dual 35 Ah AGM deep cycle batteries with onboard charging
  • Emergency stop, automatic stop when the control is released, holding brake, and keyed power-on lock
  • Two 8 in flat-free, non-marking power wheels and two 8 in swivel casters
  • Power axle release enables non-motorized use

Overall Dimensions:

45.5"W x 24.5"D x 40.5"H

Product Weight:

252.0 lb

Motorized drive

A 24-volt DC transaxle drive provides battery-operated assistance for moving loads.

Two-speed controls

Handle controls provide low and high speed settings, with forward and reverse operation.

Stainless steel construction

The cart has welded stainless steel U-frame construction with 14-gauge shelves.

Battery and charging system

Dual 35 Ah AGM deep cycle batteries work with a 120 VAC, single-phase onboard charging system with coiled cord and plug.

Safety controls

Features include an emergency stop, keyed power-on lock, holding brake, automatic stop when the operator releases the control, and a 68 dB horn.

Wheels and casters

Includes two 8 in flat-free, non-marking power wheels and two 8 in swivel casters with brakes.

Non-motorized operation

A power axle release or engagement override lever allows non-motorized use.

Related Searches

Best Sellers Bus Cart Carts & Mobile Transport Commercial Carts Lakeside Manufacturing New Arrivals Storage & Transport Storage & Transport Utility & Bussing Carts
Load capacity 1,000 lb
Number of shelves 3
Shelf style Solid
Shelf size 24.5 in x 36 in
Design Open
Construction Welded stainless steel U-frame with 14-gauge shelves
Drive motor 24 V DC transaxle
Speed settings Low: 0.1-1.5 mph; high: 0.1-3.0 mph
Battery Dual 35 Ah AGM deep cycle batteries
Charging system 120 VAC, 1-phase, 47-63 Hz, with coiled cord and plug
Power wheels Two 8 in flat-free, non-marking wheels
Casters Two 8 in swivel casters with brakes
Country of manufacture USA

Warranty & Protection

One-year equipment warranty for the original purchaser covering workmanship and materials defects when shipped.

Documents

PDF Cutsheet PDF Download PDF Sell sheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The cart has a 1,000 lb capacity.
It has three solid shelves in an open, 3-tier design.
The cart is 45.5 in wide, 24.5 in deep, and 40.5 in high, with a listed weight of 252 lb.
Yes. It uses dual 35 Ah AGM deep cycle batteries and a 24 V DC transaxle drive.
Yes. The handle controls provide forward and reverse operation with two speed settings.
Yes. A power axle release or engagement override lever allows non-motorized use.
The cart includes an emergency stop, keyed power-on lock, holding brake, automatic stop when the operator releases the control, and a 68 dB horn.
The cart is made in the USA.
