Description

La Rosa L-74166 Refrigerated Equipment Stand – 66" (2-Drawer)

Modular Equipment 74000 Series | Made in Detroit, USA

Keep cold ingredients, prep space and countertop cooking equipment right where you need them. The La Rosa L-74166 combines a heavy-duty refrigerated base with a full-length cutting board and stainless equipment shelf, delivering a true all-in-one workstation for any busy line.

Key Advantages
  • Self-contained 1/4 HP side-mounted refrigeration (R-134a) holds 36–40 °F.
  • Two full-extension drawers with removable high-impact liners for fast clean-up.
  • One-piece 304 stainless equipment shelf with ¼" marine edge & 2 ⅛" backsplash.
  • NSF-approved Richlite cutting board: 66" × 9 ½" × ½" (removable).
  • Removable equipment support rails accept fryers, griddles, charbroilers and more.
  • Rigid polyurethane foam insulation for maximum cold retention & efficiency.
  • 8" stainless legs with 1 ⅛" adjustable bullet feet for perfect leveling.
  • Ships fully welded and ready to plug in (NEMA 5-15P cord included).
Built for the Long Haul
  • Exterior surfaces are 20/22 ga 304 stainless with #4 satin finish.
  • Sound-deadening galvanized box channels support the top and shelf.
  • Drawer frames feature 1 ⅚" corrosion-resistant roller assemblies for smooth action.
  • Concealed perimeter magnets in the drawer jams ensure a positive, energy-saving seal.
  • Forced-air evaporator with protective-coated coil and an expansion-valve system for rapid temperature recovery.
  • Full finished welds resist moisture and prolong life in demanding kitchens.
Technical Specifications
Model L-74166
Overall Dimensions 66" W × 30" D × 36" H (with legs)
Refrigerated Capacity 1.6 cu ft (2 drawers)
Temperature Range 36–40 °F
Refrigeration System 1/4 HP hermetically sealed condenser, side-mounted, R-134a
Electrical 115 V / 60 Hz / 1 Ph, 8.7 A, NEMA 5-15P
Cutting Board Richlite, 66" L × 9 ½" W × ½" T
Equipment Shelf One-piece 304 stainless, ¼" marine edge, 2 ⅛" backsplash
Legs 8" stainless, bullet feet with 1 ⅛" adjustment
Shipping Weight ≈ 475 lb
Warranty

1-year parts & labor coverage on the entire unit, plus a 1-year warranty on the compressor. Extended compressor protection is available.

Specifications are subject to change without notice. Images may show optional accessories.

Features & Specs

Manufacturer

La Rosa Refrigeration

Height

36.0in

Width

66.0in

Depth

30.5in

Shipping Weight

425.0lbs

Drawer Qty

2 drawers

Compressor HP

1/4 HP

Width

61" - 72" wide

Exterior Finish

all stainless steel exterior

Top Finish

stainless steel top

Refrigeration

self-contained, side mounted

Specifications

Equipment Stand, Refrigerated Base, two-section with drawers, self-contained, 66"W x 30" D, (2) drawers, stainless steel equipment shelf with marine front edge, removable equipment support rails, 9-1/2" Richlite cutting board, expansion valve system, full finished welds, 8" stainless steel legs, adjustable feet, side-mounted refrigeration, R134a, 1/4 HP, MADE IN DETROIT
