La Rosa Refrigeration

La Rosa Refrigeration L-10174-32 Three-Section Worktop Refrigerated Base with Doors, 74"W x 32"D, Stainless Steel Top

SKU: L-10174-32
$11,947.84
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The La Rosa Refrigeration L-10174-32 is a three-section worktop refrigerated base with doors, measuring 74 in wide, 32 in deep, and 36 in high.

It features a 16-gauge stainless steel top with rear splash, stainless steel and plastic interior, stainless steel front, painted sides, one removable shelf, and 8 in stainless steel legs with adjustable feet.

The self-contained, side-mounted refrigeration system uses an expansion valve and is specified for 115 V/60/1 power at 8.38 amps with a 1/4 HP system and NEMA 5-15P plug.

Made in Detroit. Product specifications list 1 year of parts and labor included.

Overall Dimensions:

74.0"W x 32.0"D x 36.0"H

Product Weight:

535.0 lb

Three-section door configuration

The refrigerated base has three sections and three doors.

Stainless steel worktop

The worktop is specified as 16-gauge stainless steel with a rear splash.

Removable shelf

One removable shelf is specified.

Self-contained refrigeration

The refrigeration system is self-contained, side-mounted, and uses an expansion valve.

Interior and exterior construction

The interior is stainless steel and plastic; the front is stainless steel and the sides are painted.

Adjustable legs

The unit includes 8 in stainless steel legs with adjustable feet.

Electrical requirements

The unit is specified for 115 V/60/1 power, 8.38 amps, 1/4 HP, and a NEMA 5-15P plug.

Manufacturing location

Made in Detroit.

Related Searches

Best Sellers Commercial Refrigeration Commercial Refrigerators La Rosa Refrigeration New Arrivals Refrigeration & Ice Refrigerators & Freezers Restaurant Equipment Undercounter & Worktop Cabinet Equipment Worktop Refrigerators Worktop Refrigerators & Freezers
Configuration Three-section worktop refrigerated base with doors
Door count 3 doors
Width 74 in
Depth 32 in
Height 36 in
Worktop 16-gauge stainless steel with rear splash
Shelf 1 removable shelf
Interior Stainless steel and plastic
Exterior front Stainless steel
Exterior sides Painted
Refrigeration Self-contained, side-mounted
Refrigeration system Expansion valve system
Voltage / cycle / phase 115 V / 60 / 1
Amperage 8.38 A
Compressor horsepower 1/4 HP
Plug NEMA 5-15P
Legs 8 in stainless steel with adjustable feet
Weight 535 lb
Manufacturing location Made in Detroit

Warranty & Protection

One-year equipment warranty from the date of shipment for defects in material and workmanship under normal use.

Documents

PDF Cutsheet PDF Download PDF Installation & operation PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The unit is 74 in wide, 32 in deep, and 36 in high.
It has three doors serving its three sections.
It uses a self-contained, side-mounted refrigeration system with an expansion valve.
The product is specified for 115 V/60/1 power at 8.38 amps, with a 1/4 HP system and NEMA 5-15P plug.
It has a 16-gauge stainless steel worktop with rear splash.
The authoritative product specification lists one removable shelf.
The product specification lists 1 year of parts and labor included. The warranty sheet states a one-year equipment warranty from the date of shipment for defects in material and workmanship under normal use; its labor terms specify no-charge labor for 90 days, with an additional nine months potentially available at extra charge for most units.
