Krowne KRPT-54BLP-10 Royal Series Bar Equipment
Description
Royal Series 54" Pass-Thru Ice Bin & Cocktail Station
Model KRPT-54ALP-10 • Ice Bin on Left • 10-Circuit Cold PlateEngineered for high-volume beverage programs, the Krowne Royal Series pass-thru workstation packs an ice bin, cold plate, dump sinks, speedrail, blender shelf and more into a single 54" wide unit. Its through-body design speeds service on both the bartender and server sides while the all-stainless construction guarantees years of corrosion-free performance.
Why You’ll Love It
- 24" pass-thru ice bin with foamed-in-place insulation & 10-circuit cast-aluminum cold plate (5/16" S/S tubing).
- Dual-side workflow – 12" drainboard (server side) & 12" insulated bottle well (bar side) keep both lanes moving.
- 36" sound-deadened double speedrail keeps top movers right at hand.
- Two 10" × 14" × 7" dump sinks on the right, each pre-plumbed with drains and topped by a low-lead Royal Series gooseneck faucet.
- Dedicated 16" blender shelf with underside duplex outlet—no more counter clutter.
- 18" deep perforated glass shelf (with drain) protects glassware and speeds drying.
- 4" tubing chase with soda gun holder for clean, code-compliant line routing.
- Heavy-duty 20/22 ga stainless steel throughout, plus side panels & 16 ga tubular legs with grey bullet feet.
- NSF-2 listed and ASME A112.19.3/CSA B45.4 compliant.
At-a-Glance Specs
| Overall Width | 54" (1372 mm) |
|---|---|
| Overall Depth | 45" (1143 mm) |
| Overall Height | 45" (1143 mm) including glass shelf |
| Working Height | 30" (762 mm) |
| Ice Bin Interior | 24" W × 30-1/2" D |
| Cold Plate | 10 circuits, cast aluminum, 5/16" S/S tubing |
| Speedrail | 36" double, sound-deadened |
| Dump Sinks | (2) 10" × 14" × 7" bowls |
| Blender Shelf | 16" W with duplex electrical outlet |
| Glass Shelf | 18" D perforated S/S with drain |
| Drainboard | 12" W (server side) |
| Bottle Storage | 12" W insulated well (bar side) |
| Construction | 20/22 ga S/S body & shelves, 16 ga S/S legs, grey plastic bullet feet |
| Shipping Weight | Approx. 503 lb (228 kg) |
| Plumbing Connections |
1/2" IPS hot & cold water 1/2" IPS drain (cold plate) 1" IPS drain (shelves) 1-1/2" IPS drain (sink bowls) |
| Certifications | NSF 2, ASME A112.19.3 / CSA B45.4 |
Plumbing and electrical hookups must be performed by licensed professionals in accordance with all applicable codes.
Need overshelves, floor panels, or sliding ice-bin covers? Krowne offers a full line of Royal Series accessories to customize this station for your bar’s unique workflow.
