Krowne KR24-MS38R-10 Royal Series Bar Equipment
Description
Royal Series 38" Elixir Mixology Multi-Station w/ 10-Circuit Cold Plate
Krowne model KR24-MS38R-10 • Right-side ice bin • NSF & ETL-SanitationEngineered for high-volume craft cocktail bars, the Krowne Royal Series 38" Elixir Mixology Multi-Station delivers an all-in-one prep, ice and bottle service solution that keeps bartenders fast and organized. A factory-sealed 10-circuit cold plate chills beverages on demand, while the generous 92 lb ice bin and insulated bottle well put the essentials right where you need them.
Key Features
- 10-circuit cast-aluminum cold plate sealed into the ice bin for consistent drink chilling
- 30" deep, right-side ice bin holds up to 92 lbs of ice • includes 2 adjustable dividers
- Removable eight-cup garnish station with integrated cover to keep fruit fresh and protected
- Foamed-in-place polyurethane insulation throughout for maximum ice retention
- Insulated bottle well stores up to 10 elixir / cheater bottles (bottles not included)
- Integrated speed rail accommodates 10 liquor bottles for quick, ergonomic pours
- 20-gauge type-300 stainless steel interior, front apron, sides & backsplash for superior durability
- Standard 24" front-to-back depth matches common underbar equipment lines
- 1 ½" tubular stainless legs with adjustable bullet feet
- ½" IPS drain connection on the ice bin with cold plate for simple hook-up
Technical Specifications
| Model | KR24-MS38R-10 |
|---|---|
| Overall width | 38" (965 mm) |
| Front-to-back depth | 24" (610 mm) |
| Working height (to work surface) |
30" (762 mm) |
| Backsplash height | 6 ½" (165 mm) |
| Ice bin size (W × D × H) | 30" × 12" × 12" |
| Ice capacity | 92 lb (41.7 kg) |
| Cold plate | 10 circuits • 5/16" O.D. stainless tubing |
| Garnish cup capacity | 8 cups |
| Elixir bottle capacity | 10 bottles |
| Liquor bottle capacity (speed rail) | 10 bottles |
| Ice bin dividers | 2 adjustable dividers included |
| Primary drain size | ½" IPS (ice bin w/ cold plate) |
| Materials | 20-ga. stainless steel (interior, front, sides, backsplash) • 20-ga. galvanized back & bottom |
| Certifications | NSF, ETL-Sanitation |
| Shipping weight | 233 lb (105.7 kg) |
Bottles, glassware and plumbing fittings are shown for illustration only and are not included. Due to ongoing product improvements, specifications are subject to change without notice.
