Kolpak Boltover Walk-In Freezer Door Section Assembly, Left-Hinged, 46 x 86-1/4 In., 4-In. Sill

SKU: 900956
$3,965.22
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Refrigeration Kolpak New Arrivals Refrigeration, Freezing & Ice Restaurant Equipment Walk-in Coolers Walk-In Coolers & Freezers Walk-in Refrigerators

Kolpak Boltover Walk-In Freezer Door Section Assembly, Left-Hinged, 46 x 86-1/4 In., 4-In. Sill

Designed for floorless or floored applications; standard Galvalume finish.

A heavy-duty freezer door section that bolts to an existing frame and comes with the hardware and heater components needed for reliable walk-in performance.

  • Replacement freezer door section for walk-in coolers/freezers; bolts directly to an existing door frame.
  • 4-inch sill is designed for floorless applications and can also be used in floored installations.
  • Left-hinged swinging door plug with locking pull handle and inside lever release.
  • Includes hydraulic closer, two spring-loaded hinges, switch with pilot light, and a 2-inch dial thermometer.
  • Freezer-ready package includes door heater with trim, threshold, and vent.
  • Standard 26-gauge embossed Galvalume interior/exterior; additional finish options are available.
  • Shipped loose for field installation.
  • Interior and exterior kickplates are 36 inches high for added durability.

Overall Dimensions:

46.0"W x 4.0"D x 86.25"H

Product Weight:

200.0 lb

Direct-Bolt Replacement

Bolts directly to an existing door frame and is intended to replace cooler or freezer walk-in doors.

Floorless-Ready Sill

Includes a 4-inch sill for floorless applications and is also suitable for floored installations.

Left-Hinged Door Plug

The swinging door plug is built as a left-hand hinged unit for the specified opening.

Heavy-Duty Hardware

Includes a hydraulic door closer, two spring-loaded hinges, and brushed hardware for dependable daily use.

Locking Pull Handle

Padlockable pull handle with inside lever release helps secure the door while still allowing easy exit.

Freezer-Specific Components

Freezer versions include a door heater with trim, threshold, and heated vent components.

Temperature Display and Switch

A 2-inch dial thermometer and switch with pilot light are included and shipped loose for field installation.

Durable Galvalume Construction

Standard 26-gauge embossed Galvalume interior and exterior finish with 36-inch high aluminum kickplates.

Type Walk-In Freezer Door Section Assembly
Style Left Hinged
Material Galvalume
Finish Embossed Galvalume
Controls Switch With Pilot Light
Voltage 115 Volts
Amps 2.0 Amps
Hertz 60 Hz
Phase 1-Phase
Shipping Width 46 Inches
Shipping Depth 4 Inches
Shipping Height 87 Inches
Shipping Weight 200 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Documents

PDF Cutsheet PDF Download PDF Flyer PDF Download PDF Installation & operation PDF Download PDF Diagram PDF Download

Frequently Asked Questions

This specific model is the freezer version and includes freezer-specific heater, trim, threshold, and vent components.
Yes. It includes a 4-inch sill and is designed for floorless applications; the flyer also notes it can be used in floored applications.
Included hardware includes a hydraulic door closer, two spring-loaded hinges, a locking pull handle with inside release, a switch with pilot light, and a 2-inch dial thermometer.
The door section is listed at 46 inches by 86-1/4 inches overall, and the swinging door plug is 34 inches by 78 inches net opening.
Standard finish is 26-gauge Galvalume. Optional finishes mentioned include white 26-gauge Galvalume, .040 natural stucco aluminum, and 22-gauge 304 stainless steel.
