Kolpak

Boltover Freezer Walk-In Door Section Assembly, Right Hinged, 34 x 78 Door, 4-Inch Sill

SKU: 900954
$3,965.22
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Refrigeration Kolpak New Arrivals Refrigeration, Freezing & Ice Restaurant Equipment Walk-in Coolers Walk-In Coolers & Freezers Walk-in Refrigerators

Boltover Freezer Walk-In Door Section Assembly, Right Hinged, 34 x 78 Door, 4-Inch Sill

46 x 86-1/4 Inches overall; designed for floorless applications

A retrofit-ready freezer door section that bolts to an existing walk-in frame and includes the freezer-specific heater, vent, hardware, and field-installed controls.

  • Bolts directly to an existing walk-in door frame for replacement applications.
  • 4-inch sill is designed for floorless applications.
  • 34 x 78 right-hinged door plug with 36-inch-high aluminum kickplates inside and out.
  • 26-gauge embossed Galvalume interior and exterior for durable use.
  • Includes locking handle, door closer, two spring-loaded hinges, switch with pilot light, and a 2-inch dial thermometer shipped loose.
  • Freezer version includes a door heater with trim, threshold, and vent.

Overall Dimensions:

46.0"W x 4.0"D x 86.25"H

Product Weight:

200.0 lb

Bolt-On Door Section

Designed to bolt directly to an existing door frame for walk-in cooler or freezer retrofit use.

4-Inch Sill

Built with a 4-inch sill for floorless applications.

Right-Hinged Door Plug

Includes a 34 x 78 inch right-hinged door plug.

Galvalume Construction

26-gauge embossed Galvalume interior and exterior for a durable finish.

36-Inch Kickplates

Interior and exterior aluminum kickplates help protect the door from wear and impact.

Included Hardware Package

Brushed hardware includes a locking handle, door closer, and two spring-loaded hinges.

Freezer-Ready Components

Includes a door heater with trim, threshold, and vent for freezer applications.

Field-Installed Accessories

The switch with pilot light and 2-inch dial thermometer are shipped loose for field installation.

Type Freezer Door Section Assembly
Style Right Hinged
Door Size 34 x 78 Inches
Sill Height 4 Inches
Material Galvalume
Interior Finish Galvalume
Finish Embossed
Controls Switch With Pilot Light
Voltage 115 Volts
Amps 20 Amps
Hertz 60 Hz
Phase 1-Phase
Shipping Width 46 Inches
Shipping Depth 4 Inches
Shipping Height 87 Inches
Shipping Weight 200 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Documents

PDF Cutsheet PDF Download PDF Diagram PDF Download PDF Flyer PDF Download PDF Installation & operation PDF Download

Frequently Asked Questions

Yes. It includes a 4-inch sill designed for floorless applications.
The door plug is 34 x 78 inches and is right hinged.
It includes a door heater with trim, threshold, vent, locking handle, door closer, two spring-loaded hinges, switch with pilot light, and a 2-inch dial thermometer shipped loose.
Yes. The documentation states it is designed for both floorless and floored applications.
Yes. A third hinge and a 14 x 14 viewport are listed as accessories.
Optional finishes include white 26-gauge Galvalume, .040 natural stucco aluminum, and 22-gauge 304 stainless steel.
