Kolpak

Kolpak Boltover Walk-In Cooler Door Section Assembly, Right Hinged, No Sill, 46 x 82-1/4 Inches

SKU: 900949
$3,603.96
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Refrigeration Kolpak New Arrivals Refrigeration, Freezing & Ice Restaurant Equipment Walk-in Coolers Walk-In Coolers & Freezers Walk-in Refrigerators

Kolpak Boltover Walk-In Cooler Door Section Assembly, Right Hinged, No Sill, 46 x 82-1/4 Inches

Flat Bottom, 34 x 78 Inch Door Plug, Embossed Galvalume

Built for floorless walk-ins, this bolt-on door section combines a no-sill design with heavy-duty hardware for a durable replacement fit.

  • No-sill, flat-bottom design is made for floorless walk-in cooler applications.
  • 46 x 82-1/4 inch door section with a 34 x 78 inch right-hinged door plug.
  • 26-gauge embossed Galvalume interior and exterior for long-lasting durability.
  • Includes a hydraulic closer, locking handle, two spring-loaded hinges, and 36-inch kickplates.
  • Switch with pilot light and 2-inch dial thermometer ship loose for field installation.
  • Designed to bolt directly to an existing door frame for replacement installations.

Overall Dimensions:

46.0"W x 4.0"D x 82.25"H

Product Weight:

200.0 lb

Bolt-On Replacement Design

Bolts directly to an existing door frame for walk-in replacement installations.

No-Sill Floorless Design

Flat bottom construction is designed for floorless applications with no sill.

Galvalume Construction

26-gauge embossed Galvalume on the interior and exterior for durability.

Right-Hinged Door Plug

The swinging door plug measures 34 x 78 inches and is configured for right-hand operation.

Heavy-Duty Hardware Package

Includes a hydraulic door closer, padlockable locking handle with inside lever release, and two spring-loaded hinges.

Field-Installed Components

The switch with pilot light and 2-inch dial thermometer ship loose for field installation.

Protective Kickplates

36-inch high aluminum kickplates on the interior and exterior help protect the door from wear.

Type Walk-In Cooler Door Section Assembly
Style Right Hinged
Material Galvalume
Finish Embossed Galvalume
Voltage 115 Volts
Amps 1.0 Amps
Hertz 60 Hz
Phase 1-Phase
Selling Unit Each
Units Per Case 1
Shipping Width 46 Inches
Shipping Depth 4 Inches
Shipping Height 83 Inches
Shipping Weight 200 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Documents

PDF Cutsheet PDF Download PDF Installation & operation PDF Download PDF Diagram PDF Download PDF Flyer PDF Download

Frequently Asked Questions

Yes. It has a flat bottom and no sill, which makes it suitable for floorless applications.
The overall section measures 46 x 82-1/4 inches, and the door plug is 34 x 78 inches.
It includes a hydraulic door closer, locking handle with inside lever release, two spring-loaded hinges, 36-inch kickplates, a switch with pilot light, and a 2-inch dial thermometer.
No. The switch with pilot light and the 2-inch dial thermometer ship loose for field installation.
Yes. The documentation lists White 26 Ga. Galvalume, .040 Natural Stucco Aluminum, and 22 Ga. 304 Stainless Steel as additional finish options.
